Home / Long-Barrel Splice, 3.75 in. L, Blue

Long-Barrel Splice, 3.75 in. L, Blue

SKU
Brand Abb Installation Products
Categories
Description Long-Barrel Splice, Barrel Finish Tin Plated, Barrel Size Long, Color Code Blue, Die Code 76, For Conductor Material Copper, For Wire Type Flex Wire, Material Copper, Maximum Voltage 35 kV, Minimum Wire Size 400 kcmil, Maximum Wire Size 400 kcmil, Number of Crimps 4, Overall Length 3.75 in, Maximum Conductors 1, Maximum Operating Temperature 194 Degrees F, RoHS Compliant Yes, Seam Style Seamless, Standards CSA Certified, UL Listed, Barrel Outside Diameter 0.98 in
graingerSKU: , mscSKU: , zoro_no: G2889451, mongo_id: 65bbe5fa3aaddbd5a9ffc377

Web Price

$50.61 / each

Qty

Product Details

Application Applications certified to 600 V and recommended up to 35 kVÃÂ¥

AWG-range 400-400

Barrel Finish Tin Plated

Barrel Outside Diameter 0.98 in

Barrel Size Long

Color Blue

Color Code Blue

Compatible with Product Type Copper Conductor

Conductor Range 400-400

Contact Finish Tin

Contact Material Copper

Country of Origin (subject to change) Mexico

Die Code 76

For Conductor Material Copper

For Wire Size 400 kcmil

For Wire Type Flex Wire

Insulation Material None

Length 3.75 in

Length (Straight Wireway) 3.75 in

Material Copper

Maximum Conductors 1

Maximum Operating Temperature 194 Degrees F

Maximum Voltage 35 kV

Maximum Wire Insulation Diameter 0.98 in

Maximum Wire Size 400 kcmil

Minimum Wire Size 400 kcmil

Number of Batteries 0

Number of Crimps 4

Outside Dia. 0.98 in

Overall Length 3.75 in

Package Quantity 1

Product Name ELECTRICAL TERMINAL

Product Type Splice Connector

RoHS Compliant Yes

Seam Style Seamless

Special Features Easy To Insulate and Provide a Low-Resistance Connection of High Quality and Low Installed Cost, Two-Way Connectors Provide High Pullout Values

Special Functions Two-way connectors provide high pullout values, are easy to insulate and provide a low-resistance connection of high quality and low installed cost.

Standard UL E9809, CSA 4503

Standards CSA Certified, UL Listed

Surface Finishing Tin Plated

Surface protection Tinned

Termination Style Crimp

Type of connection End connector

Voltage level Up to 35 kV

Voltage Rating 600 V

Wire Gauge 400 kcmil
