Lug Alum/Copper 1 Hole, PK2

SKU
Brand Abb Installation Products
Categories
Description One-Hole Lug Compression Connector, Barrel Size Long, Color Code Brown, Die Code 87H, Tongue Angle Straight, Tongue Width 1.53 in, For Conductor Material Copper, For Stud Size 1/2 in, For Stranded Copper Wire Size - Maximum 350 kcmil, Inspection Hole No, Hole Center to Center Not Applicable, Material Aluminum, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 35 kV AC, Standards CSA Certified, UL E9809, Number of Holes 1, Barrel Outside Diameter 1.09 in, Connector Type Straight Barrel

Web Price

$28.24 / each

Qty

Minimum order: 2

Product Details

Barrel Length Long

Barrel Outside Diameter 1.09 in

Barrel Size Long

Cable Size 350 kcmil

Color Code Brown

Connector Type Long Barrel

Contact Finish Tin

Country of Origin (subject to change) Mexico

Die Code 87H

For Conductor Material Copper

For Stranded Aluminum Wire Size - Maximum 350 kcmil

For Stranded Copper Wire Size - Maximum 350 kcmil

For Stud Size 1/2 in

For Wire Size 350 kcmil

For Wire Type Solid, Stranded

Hole Center to Center Not Applicable

Hole Center to End 0.5 in

Hole Size 0.5 in

Inspection Hole No

Insulation None

Length 4.83

Length (Straight Wireway) 4.83 in

Material Electro-Tin Plated High-Conductivity Wrought Aluminum

Maximum Operating Temperature 194 Degrees F

Maximum Voltage 35 kV AC

Number Of Holes 1

Overall Length 4.83 in

Overall Width 1.53 in

Package Quantity 2

Peep Hole No

Plate Material Tin

Special Features Easily Matched to the Correct Blackburn, Filled With High Temperature Oxide-Inhibitor Compound, Long Compression Areas Ensure Complete Contact

Standard UL E9809

Standards CSA Certified, UL E9809

Stud Size 1/2 in

Tongue Angle Straight

Tongue Length 1.25 in

Tongue Style Standard

Tongue Width 1.53 in

Tongue Width Ranges 1.50 inches and wider

Voltage Rating 35 kV

Width 1.53

Wire Size Range 350 kcmil

Wire Size Ranges 350 kcmil
