Short-Barrel Splice, 2.13 in., White

SKU
Brand Abb Installation Products
Categories
Description Short-Barrel Splice, Barrel Finish Tin Plated, Barrel Size Standard, Color Code White, Die Code 66, For Conductor Material Copper, For Wire Type Class G, H, I, K, M, Material Copper, Maximum Voltage 35 kV, Minimum Wire Size 300 kcmil, Maximum Wire Size 300 kcmil, Number of Crimps 1, Overall Length 2.13 in, Maximum Conductors 1, Maximum Operating Temperature 194 Degrees F, RoHS Compliant Yes, Seam Style Seamless, Standards CSA Certified, UL Listed, Barrel Outside Diameter 0.83 in
graingerSKU: , mscSKU: , zoro_no: G1430204, mongo_id: 65bbe5b43aaddbd5a9fdf4e7

Web Price

$25.19 / each

Qty

Minimum order: 5

Product Details

Application Applications certified to 600 V and recommended up to 35 kVÃÂ¥

Barrel Finish Tin Plated

Barrel Outside Diameter 0.83 in

Barrel Size Standard

Color White

Color Code White

Compatible with Product Type Copper Conductor

Contact Finish Tin

Contact Material Copper

Country of Origin (subject to change) Mexico

Die Code 66

For Conductor Material Copper

For Wire Size 300 kcmil

For Wire Type Class G, H, I, K, M

Insulation None

Length 2.13 in

Length (Straight Wireway) 2.13 in

Material Copper

Maximum Conductors 1

Maximum Operating Temperature 194 Degrees F

Maximum Voltage 35 kV

Maximum Wire Insulation Diameter 0.83 in

Maximum Wire Size 300 kcmil

Minimum Wire Size 300 kcmil

Number of Batteries 0

Number of Crimps 1

Outside Dia. 0.83 in

Overall Length 2.13 in

Package Quantity 1

Product Name ELECTRICAL TERMINAL

Product Type Splice

RoHS Compliant Yes

Seam Style Seamless

Special Features Easy To Insulate and Provide a Low-Resistance Connection of High Quality and Low Installed Cost, Two-Way Connectors Provide High Pullout Values

Special Functions Two-way connectors provide high pullout values, are easy to insulate and provide a low-resistance connection of high quality and low installed cost.

Standard UL E9809

Standards CSA Certified, UL Listed

Surface Finishing Tin-Plated

Surface protection Tinned

Termination Style Crimp

Voltage Rating 600 V

Wire Gauge 300 kcmil
