Home / Short-Barrel Splice, 2.75 in. L, Brown

Short-Barrel Splice, 2.75 in. L, Brown

SKU
Brand Abb Installation Products
Categories
Description Short-Barrel Splice, Barrel Finish Tin Plated, Barrel Size Standard, Color Code Brown, Die Code 87, For Conductor Material Copper, For Wire Type Class G, H, I, K, M, Material Copper, Maximum Voltage 35 kV, Minimum Wire Size 500 kcmil, Maximum Wire Size 500 kcmil, Number of Crimps 2, Overall Length 2.75 in, Maximum Conductors 1, Maximum Operating Temperature 194 Degrees F, RoHS Compliant Yes, Seam Style Seamless, Standards CSA Certified, UL Listed, Barrel Outside Diameter 1.11 in
graingerSKU: , mscSKU: , zoro_no: G2374251, mongo_id: 65bbe86b22d7a989a98f432e

Web Price

$26.86 / each

Qty

Product Details

Application Applications certified to 600 V and recommended up to 35 kVÃÂ¥

Barrel Finish Tin Plated

Barrel Outside Diameter 1.11 in

Barrel Size Standard

Color Brown

Color Code Brown

Compatible with Product Type Copper Conductor

Contact Finish Tin

Contact Material Copper

Country of Origin (subject to change) Mexico

Die Code 87

Features Two-way connectors provide high pullout values, are easy to insulate and provide a low-resistance connection of high quality and low installed cost.

Finish Tin-Plated

For Conductor Material Copper

For Wire Size 500 kcmil

For Wire Type Class G, H, I, K, M

Length 2.75 in

Length (Straight Wireway) 2.75 in

Material Copper

Maximum Conductors 1

Maximum Operating Temperature 194 Degrees F

Maximum Voltage 35 kV

Maximum Wire Insulation Diameter 1.11 in

Maximum Wire Size 500 kcmil

Minimum Wire Size 500 kcmil

Number of Crimps 2

Outside Dia. 1.11 in

Overall Length 2.75 in

Package Quantity 1

RoHS Compliant Yes

Seam Style Seamless

Special Features Easy To Insulate and Provide a Low-Resistance Connection of High Quality and Low Installed Cost, Two-Way Connectors Provide High Pullout Values

Standard UL E9809

Standards CSA Certified, UL Listed

Surface protection Tinned

Termination Style Crimp

Type Splice

Voltage Rating 600 V

Wire Gauge 500 kcmil
