Pin & Sleev Plug, 20A, 3P, 2W, Alum, 125/250V

SKU
Brand Appleton Electric
Categories
Description Pin and Sleeve Plug, Current Rating 20 A, Hazardous Location Specification Class I, Div 1 and 2, Group C, D, Horsepower Rating 1 hp, Housing Color Gray, Number of Poles 3, Number of Wires 2, Phase Single, Voltage Rating 125 to 250V AC, Cap Type No Cap or Cover, Connection Orientation Straight, Face Diameter 1.56 in, For Maximum Cable Diameter 0.639 in, For Minimum Cable Diameter 0.538 in, Grounding Grounded, Housing Material Copper-Free Aluminum, Outside Diameter 1.86 in, Reverse Service No
graingerSKU: 12G209, mscSKU: , zoro_no: G7555012, mongo_id: 65bbea6522d7a989a99b04d0

Web Price

$363.74 / each

Product Details

Amperage 20

Amps 20 A

Cap Type No Cap or Cover

Compatible with Series Contender(TM) CPS

Connection Orientation Straight

Country of Origin (subject to change) Mexico

Current Rating 20 A

Face Diameter 1.56 in

Features Plug and Receptacles are Supplied with Pressure Terminal Connectors

For Environment Corrosive, Damp, Hazardous Location

For Maximum Cable Diameter 0.639 in

For Minimum Cable Diameter 0.538 in

Grounding Grounded

Hazardous Area Classification Class I, Division 1 and 2, Groups C, D

Hazardous Location Specification Class I, Div 1 and 2, Group C, D

Horsepower Rating 1 hp

Horsepower Ratings 1

Housing Color Gray

Housing Material Metallic

Housing Material Finish Epoxy Coat with Powder Finish

HP_ 1 hp

Insulation Material Fiberglass-Reinforced Polyester

Material Copper-Free Aluminum

Materials and Finishes Receptacle cover and CPP plug is copperfree (4/10 of 1% max.) aluminum with epoxy powder coat. Mounting box is malleable iron with triple-coat. Insulating blocks are fiberglass reinforced polyester.

Mounting Box Entries Dead-End or Feed-Thru

Number of Poles 3

Number of Wires 2

Outside Diameter 1.86 in

Overall Length 4.81 in

Package Quantity 1

Phase Single

Pin & Sleeve Standards cUL Listed, UL Listed

Plug Cable Diameter .538- .639

Reverse Service No

Standards cULus E10784, UL 1010, UL 1203, UL 894

Switch Rated No
