Home / Insulated Flexible Duct, 25 ft. L, 140F

Insulated Flexible Duct, 25 ft. L, 140F

SKU
Brand Atco
Categories
Description Flexible Duct, For Nominal Duct Diameter 16 in, Wall Thickness 2.5 in, Maximum Temperature Rating 140 Degrees F, Minimum Temperature Rating -20 Degrees F, Insulation Value R 8.0, Color Gray, Overall Length 25 ft, Duct Material Fiberglass, Jacket Material Polyester, Fire Rating Flame Spread: 25 Max; Smoke Developed: 50 Max, Maximum Pressure Rating 6 in wc, Maximum Air Speed 5,000 fpm, Vapor Transmission 0.6 Percent
graingerSKU: , mscSKU: , zoro_no: G1923485, mongo_id: 65bbe64c3aaddbd5a901ed90

Web Price

$261.24 / each

Qty

Product Details

Color Gray

Compressed Length 38 in

Compressed Size 38 in

Country of Origin (subject to change) United States

Duct Material Fiberglass

End Type Plain

Environment Type Indoor

Features Double Ply Vapor Barrier with Tri Directional Reinforcements

Fire Rating Flame Spread: 25 Max; Smoke Developed: 50 Max

Flexibility Flexible

Flexible Duct Inside Dia. 16 in

Flexible Duct Item Insulated Flexible Duct

Flexible Duct Length 25 ft

Flexible Duct Wall Thickness 2 1/2 in

For Nominal Duct Diameter 16 in

For Use With Low Pressure Air Moving Systems

Inside Diameter 16 in

Insulation Material Fiberglass

Insulation Value R 8.0

Interior Surface Texture Smooth

Jacket Material Polyester

Low Temp. Deg. -20F

Material Polyester

Max. Air Flow 5,000 fpm

Max. Pressure 6 in WC

Max. Temp. 140F

Maximum Air Speed 5,000 fpm

Maximum Continuous Length 100 ft

Maximum Pressure Rating 6 in wc

Maximum Temperature Rating 140 Degrees F

Minimum Temperature Rating -20 Degrees F

Overall Length 25 ft

Package Quantity 1

Product Type Insulated Flexible Duct

Standards California State Fire Marshal, City of Chicago, Dade County, Florida, cUL Listed, HUD, IMC, IRC, New York City, NFPA 90A & B, City of San Francisco, UL Listed, UMC

System of Measurement Inch

UPC Number 78

Vapor Transmission 0.6 %

Wall Thickness 2.5 in
