Mechanical Conn, 500 kcmil to 1/0 AWG
Mechanical Conn, 500 kcmil to 1/0 AWG
Mechanical Conn, 500 kcmil to 1/0 AWG

Mechanical Conn, 500 kcmil to 1/0 AWG

  • Blackburn
  • Mechanical Connector, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 1/0 AWG, For Stranded Copper Wire Size - Maximum 500 kcmil, For Stud Size 13/32 in, Head Style Hex, Number of Holes 1, Hole Diameter 0.41 in, Hole Spacing Not Applicable, Body Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 1,000 V, Number of Conductors 1, Number of Terminations 1, Tongue Length 2 in, Tongue Width 1.5 in, Tongue Thickness 0.19 in, Tongue Offset Height 0.5 in

    graingerSKU: 3LN78, mscSKU: , zoro_no: G2074642, mongo_id: 65bbe76f9a749db82273a2a4

Web Price
$64.61 / each
Qty

Product Details

Copper
Offset Tang
Offset Tang
Mexico
Uniquely designed pressure bar and notched v-bottom collar provide vise-like grip between conductor and terminal.; Made of electrolytic seamless copper. Screws are zinc-plated steel.
Copper
500 kcmil
1/0 AWG
13/32 in
2/0 AWG, 250 kcmil, 3/0 AWG, 300 kcmil, 350 kcmil, 4/0 AWG, 400 kcmil, 450 kcmil, 500 kcmil
Hex
0.41 in
Not Applicable
4.25 in
4.25 in
Electrolytic Copper
500 kcmil Stranded
194 Degrees F
1,000 V
1/0 AWG Stranded
1
1
1
1
2 11/16 in
4.25 in
1.5 in
1
ELEC CONNECTOR <1000V
Copper Connectors
Zinc Plated
Steel
Notched V-Bottom Collar, Uniquely Designed Pressure Bar
Uniquely designed pressure bar and notched v-bottom collar provide vise-like grip between conductor and terminal.
UL E9809
UL Listed, UL486A/B
13/32 in
2 in
0.5 in
0.19 in
1.5 in
UL 486A-486B
1.5 in
1/0 AWG - 500 kcmil
