Home / 3" ID x 15 ft Nitrile Frac Gasoline Hose BK

3" ID x 15 ft Nitrile Frac Gasoline Hose BK

SKU
Brand Boston
Categories
Description Frac Gasoline Hose, Hose Inside Dia. 3 in, Hose Outside Dia. 3 11/16 in, Hose Length 15 ft, Hose Tube Material Nitrile, Hose Cover Material UHMW-PE, Hose Color Black, Max. Working Pressure @ 70 F 400 psi, Vacuum Rating Not Rated, Temp. Range -40 Degrees to 200 Degrees F, Standards RMA Class A, Hose Configuration Coupled Assembly, Hose Fitting A Material Carbon Steel, Hose Fitting B Material Carbon Steel, Hose Fitting A Type M Frac FTG, Hose Fitting B Type F Frac FTG, Hose Fitting A Size 3 in
graingerSKU: 45CV48, mscSKU: , zoro_no: G2473278, mongo_id: 65bbe88a9a749db822797f6a

Web Price

$2,087.49 / each

Qty

Product Details

Color Black

Compatible Chemicals Air, Antifreeze (Coolant), Diesel Fuel, Ethylene Glycol, Fresh Water, Fuel Oil, Gasoline, Heptane, Hydraulic Fluid (Petroleum), Hydraulic Fluid (Synthetic), Kerosene, Lubricated Air, Methyl (Methanol), Mineral Oil , Motor Oil, Salt Water, Stoddard Solvent (Mineral Spirits), Vegetable Oil

Country of Origin (subject to change) United States

Coupled Assembly / Bulk Coupled Assembly

Couplers M and F Steel Frac

Cover Material Bruiser

Fitting Material Carbon Steel x Carbon Steel

Fitting Size 3 in x 3 in

Fitting Type M Frac FTG x F Frac FTG

For Media Type Methanol, Antifreeze, Ethylene Glycol, Gasoline, Heptane, Kerosene, Stoddard Solvent, Diesel Fuel, Hydraulic Fluid, Water, Motor Oil, Air, Fuel Oil, Lubricated Air, Mineral Oil , Vegetable Oil

Fuel Hose Type Oil and Gas Exploration Hose Assembly

Gasoline Hose Inside Dia. 3

Gasoline Hose Length 15 ft.

Gasoline Hose Max. Pressure 1600 psi

Gasoline Hose Tube Material Nitrile

Gasoline Hose Type Frac Gasoline Hose

Hose Color Black

Hose Configuration Coupled Assembly

Hose Cover Material UHMW-PE

Hose Fitting A Material Carbon Steel

Hose Fitting A Size 3 in

Hose Fitting A Type M Frac FTG

Hose Fitting B Material Carbon Steel

Hose Fitting B Size 3 in

Hose Fitting B Type F Frac FTG

Hose Fittings Carbon Steel 3 in F Frac FTG x Carbon Steel 3 in M Frac FTG

Hose Inside Dia. 3 in

Hose Length 15 ft

Hose Outside Dia. 3 11/16 in

Hose Tube Material Nitrile

Inside Dia. 3

Inside Dia. - Gasoline Hose 3

Length 15 ft.

Length - Gasoline Hose 15 ft.

Max. Pressure - Gasoline Hose 1600 psi

Max. Working Pressure @ 70 F 400 psi

Meets RMA Class A

Not Recommended Chemicals Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Acetone, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Citric Acid 50%, Formic Acid, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Methyl Ethyl Ketone (MEK), Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Phosphoric Acid (40% Solution), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Sulfuric Acid (to 10%)

Outside Dia. 3-11/16

Package Quantity 1

Reinforcement 4-Ply Polyester

Standards RMA Class A

Temp. Range -40 Degrees to 200 Degrees F

Tube Material Nitrile

Tube Material - Gasoline Hose Nitrile

Type - Gasoline Hose Frac Gasoline Hose

Vacuum Rating Not Rated
