Home / Instrumentation Fittings, 1/4", Plug, SS

Instrumentation Fittings, 1/4", Plug, SS

SKU
Brand Brennan Industries
Categories
Description Instrumentation Fittings, Fitting Material Stainless Steel, Material Grade 316, Maximum Operating Pressure 6,696 psi, Maximum Operating Temperature 100 Degrees F, Specific Fitting Shape Ferrule Set, System of Measurement Imperial, Compatible Fitting Brands Parker A-LOK; Swagelok, Compatible Tube Outer Diameter 1/2 in, Series Brennan Instrumentation, Standards ASME B31.3-2002, ASTM A213, ASTM A269, Compatible Fitting Connection Type Compression, Compatible Tube Hardness 90 HRB
graingerSKU: 782KA3, mscSKU: , zoro_no: G605386476, mongo_id: 65bbe83a22d7a989a98e3765

Web Price

$5.24 / each

Qty

Product Details

Compatible Fitting Brands Parker A-LOK; Swagelok

Compatible Fitting Connection Type Compression

Compatible Tube Hardness 90 HRB

Compatible Tube Material Stainless Steel

Compatible Tube Outer Diameter 1/2 in

Compatible Tube Wall Thickness 0.041 in

Compliance ASME Specifications, ASTM Specifications

Compression Thread Size 3/4-16

Connection Type Compression

Country of Origin (subject to change) India

End Connection Type Compression

Fitting Body Material 316 Stainless Steel

Fitting Connection Type Instrumentation

Fitting Material Stainless Steel

Fitting Shape Sleeve

For Tube OD 1/2 in

For Tube Outside Diameter 1/2 in

Hex Size 1/2 in

Material Grade 316

Max. Pressure 75000 psi

Maximum Operating Pressure 6,696 psi

Maximum Operating Temperature 100 Degrees F

Minimum Operating Temperature 20 Degrees F

Package Quantity 1

Pipe Size - Pipe Fitting 1/2 in

Series Brennan Instrumentation

Special Features All Components are Made of the Same Material for Thermal Compatibility and Corrosion Resistance, Resist Temperature Cycling, Resist Vibration, Self-Aligning, Work on Thick and Thin Wall Tubing

Specific Fitting Shape Ferrule Set

Standards ASME B31.3-2002, ASTM A213, ASTM A269

System of Measurement Imperial

Temp. Range -20 Degrees to 100 Degrees F

Tube Fitting Material Stainless Steel

Tube Size Not Applicable
