Instrumentation Fittings, 1/4", Plug, SS

SKU
Brand Brennan Industries
Categories
Description Instrumentation Fittings, Application Gas, Hydraulic, Tubing Systems, Fitting Side A Connection Type Compression, Fitting Side B Connection Type Compression, Fitting Side C Connection Type Compression, Fitting Material Stainless Steel, Fitting Side A Tube Outer Diameter 3/4 in, Fitting Side B Tube Outer Diameter 3/4 in, Fitting Side C Tube Outer Diameter 3/4 in, Thread Size C 1-20, Thread Size B 1-20, Thread Size A 1 1/16-12, System of Measurement Imperial
graingerSKU: 782KG1, mscSKU: , zoro_no: G205386418, mongo_id: 65bbe96f22d7a989a995614b

Web Price

$119.24 / each

Qty

Product Details

Application Gas, Hydraulic, Tubing Systems

Compatible Fitting Brands Parker A-LOK, Swagelok

Compatible Tube Hardness 90 HRB

Compatible Tube Wall Thickness 0.062 in

Compliance ASME Specifications, ASTM Specifications

Compression Thread Size 1 1/16-12

Connection Type Compression x Compression x Compression

Country of Origin (subject to change) India

End Connection Type Compression

Fitting Body Material 316 Stainless Steel

Fitting Connection Type Instrumentation x Instrumentation x Instrumentation

Fitting Material Stainless Steel

Fitting Shape Tee

Fitting Side A Connection Type Compression

Fitting Side A Tube Outer Diameter 3/4 in

Fitting Side B Connection Type Compression

Fitting Side B Tube Outer Diameter 3/4 in

Fitting Side C Connection Type Compression

Fitting Side C Tube Outer Diameter 3/4 in

For Tube OD 3/4 in x 3/4 in x 3/4 in

For Tube Outside Diameter 3/4 in

Hex Size 28 1/2 mm

Material Grade 316

Max. Pressure 75000 psi

Maximum Operating Pressure 2436 psi

Maximum Operating Temperature 1,200 Degrees F

Minimum Operating Temperature 20 Degrees F

Overall Length 3 5/32 in

Package Quantity 1

Pipe Size - Pipe Fitting 3/4 in x 3/4 in x 3/4 in

Series Brennan Instrumentation

Special Features All Components are Made of the Same Material for Thermal Compatibility and Corrosion Resistance, Resist Temperature Cycling, Resist Vibration, Self-Aligning, Work on Thick and Thin Wall Tubing

Specific Fitting Shape Tee

Standards ASME B31.3-2002, ASTM A269-04

System of Measurement Imperial

Temp. Range -20 Degrees to 100 Degrees F

Thread Size A 1 1/16-12

Thread Size B 1-20

Thread Size C 1-20

Threading Size 1 1/16-12 x 1-20 x 1-20

Tube Fitting Material Stainless Steel

Tube Size Not Applicable
