Divider, Flow, 2.4-5 GPM

SKU
Brand Concentric International
Categories
Description Hydraulic Flow Divider, Rotary Gear, Integral Differential Relief Valve Type, Flow Rate (GPM) 2.4-5, Displacement (cc/rev) 0.129 cc/rev, Port Size Inlet (In.) 3/4 -16, Port Size Outlet (In.) 3/4 -16, Operating Pressure (PSI) 3,000 psi, RPM Range 2000 to 4500, Max. Outer Pressure (PSI) 4,500 psi, Permananent Molded Cast Iron Body Material, 11 Tooth Hardened Steel Gears, Length (In.) 7.55 in, Width (In.) 2.99 in, Height (In.) 3.26 in
graingerSKU: 4F660, mscSKU: , zoro_no: G1302043, mongo_id: 65bbe7a23aaddbd5a90a85b0

Web Price

$447.49 / each

Qty

Product Details

Body Material Permananent Molded Cast Iron

Country of Origin (subject to change) United States

Displacement (cc/rev) 0.129

Flow Rate (GPM) 2.4-5

Function Split the Flow from a Single Pump Source to a Pair of Matched Cylinders or Fluid Motors, Synchronize Two Parallel Motions Hydraulically than Mechanically

Gears 11 Tooth Hardened Steel

Height (In.) 3.26 in

Length (In.) 7.55 in

Max. Outer Pressure (PSI) 4,500

Max. RPM 4,500 RPM

Operating Pressure (PSI) 3,000

Package Quantity 1

Port Size Inlet (In.) 3/4 -16

Port Size Outlet (In.) 3/4 -16

RPM Range 2000 to 4500

Type Rotary Gear

Valve Type Integral Differential Relief
