Home / Solid State Relay, 110 to 280VAC, 20A
Solid State Relay, 110 to 280VAC, 20A

Solid State Relay, 110 to 280VAC, 20A

  • Crydom
  • Solid State Relay, Electrical Connection Screw Clamp, Heat Sink Integral, Input Current 5 mA, Input Voltage 110 to 280V AC, Maximum Output Current with Heat Sink 20 A, Maximum Output Current without Heat Sink 20 A, Output Switching Mode Zero Crossing, Output Voltage Range 48 to 530V AC, Standards CE Certified, CSA LR81689, Designed in accordance with the requirements of IEC 62314, RoHS Compliant, UR E116950, VDE 129156, Switch Component Type SCR, Current Type AC, Finger Safe Yes

    graingerSKU: 1DTP4, mscSKU: , zoro_no: G1286993, mongo_id: 65bbe9d422d7a989a997df07

Web Price
$100.61 / each
Qty

Product Details

0.89 in
0.89 in
3.16 in
3.9 in
0.88 in
3.2 in
Black
SPST-NO
Mexico
AC
4,000V AC
1.6V DC
Screw Clamp
Screw
Yes
50/60 Hz
Integral
Integral Heat Sink
5 mA
110 to 280V AC
110 to 280VAC
0.2 to 1.0VA
110 to 280V AC
1,000 megaohm
Solid State Relay
20 A
20.0 A Integral Heat Sink
20A
8 pF
176 Degrees F
20 A
20 A
-40 Degrees F
DIN or Flange
DIN Rail, Surface
DIN Rail
24 to 530V AC
Zero Crossing
48 to 530V AC
3.95 in
3.9 in
1
1
0.5
DIN-Rail
Zero Crossing
10 msec
CKR48 Series
CE Certified, CSA LR81689, Designed in accordance with the requirements of IEC 62314, RoHS Compliant, UR E116950, VDE 129156
Green LED Indicator
SCR
Form A
SCR
Zero Cross
24 to 530VAC
AC Output
10 oz
