Solid State Relay, 4 to 32VDC, 50A

SKU
Brand Crydom
Categories
Description Solid State Relay, Electrical Connection Saddle Clamp; Screw, Heat Sink Integral, Input Current 35 mA, Input Voltage 4 to 32V DC, Maximum Output Current with Heat Sink 50 A, Maximum Output Current without Heat Sink Not Recommended, Output Switching Mode Random/Instantaneous, Output Voltage Range 48 to 530V AC
graingerSKU: 21R956, mscSKU: , zoro_no: G4476805, mongo_id: 65bbea2822d7a989a999a97b

Web Price

$364.99 / each

Qty

Product Details

Body Depth 2.89 in

Body Depth - Relay 2.89 in

Body Height 3.2 in

Body Height - Relay 0.79 in

Body Width 4.09 in

Body Width - Relay 4.09 in

Case Color Gray

Contact Form - Relay (3) SPST-NO

Country of Origin (subject to change) Mexico

Current Type DC

Dielectric Strength 4,000V AC

Drop Out Voltage 1.35V DC

Electrical Connection Saddle Clamp; Screw

Electrical Connection Type Screw

Electrical Phase Three

Finger Safe Yes

Frequency 50/60 Hz

Heat Sink Integral

Horsepower @ 240V AC 3 hp

Includes Thermal Pad

Includes Thermal Pad Yes

Input Current 35 mA

Input or Control Voltage 4 to 32V DC

Input or Control Voltage Range 4 to 32VDC

Input Power Consumption (Burden) 0.3W

Input Voltage 4 to 32V DC

Insulation Resistance 1,000 megaohm

IP Rating IP20

Item - Relay Solid State Relay

Max. Output Amps w/Heat Sink 50 A

Max. Output Amps Without Heat Sink Not Recommended

Max. Output w/Heat Sink 50A

Maximum Capacitance 8 pF

Maximum Operating Temperature 176 Degrees F

Maximum Output Current with Heat Sink 50 A

Maximum Output Current without Heat Sink Not Recommended

Minimum Operating Temperature -40 Degrees F

Mounting Surface

Mounting - Relay Surface

Mounting Style Panel

Output or Controlled Voltage Range 48 to 530V AC

Output Switching Mode Random/Instantaneous

Output Voltage Range 48 to 530V AC

Overall Depth 1.45 in

Overall Height - Relay 1.18 in

Package Quantity 1

Phase 3

Power Factor 0.5

Relay Mounting Style Surface

Relay Turns On At Instantaneous/Random

Response Time 0.1 msec

Series 53TP Series

Standards EN60950: Meets the requirements of sections1.5: 1,7: 2.9: 2.10.5.3: 4.2: 4.5: 4.7, IEC 1000-4-2, IEC 1000-4-3, IEC 1000-4-4, IEC 1000-4-5, IEC 1000-4-6, IEC 60068-2-27, IEC 60068-2-6, IEC 62314

Status Indicator LED Indicator

Switch Component Type SCR

Switch Configuration Form A

Switch Type SCR

Turns On At Instantaneous

Voltage Output 48 to 530VAC

Voltage Type AC Output

Weight 13.1 oz
