Home / AC Gearmotor, 275.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 115V AC Voltage, 1 Phase
AC Gearmotor, 275.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 115V AC Voltage, 1 Phase
AC Gearmotor, 275.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 115V AC Voltage, 1 Phase

AC Gearmotor, 275.0 in-lb Max. Torque, 27 RPM Nameplate RPM, 115V AC Voltage, 1 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 1, Motor Type Split-Phase, Motor Enclosure Totally Enclosed Fan-Cooled, Nameplate Speed 27 RPM, Maximum Torque 275 in-lb, Overhung Load Capacity 175 ft-lb, Rotation CW/CCW, Output Shaft Height 3.5 in, Mounting Orientation Any Angle, Operating Voltage 115V AC, Inverter Rated Yes, Gear Ratio 65:1, Brake Type None, Shaft Orientation Parallel, AGMA Gear Class Class 9

    graingerSKU: 6K328, mscSKU: , zoro_no: G2852367, mongo_id: 65bbe5d03aaddbd5a9fea1c8

Web Price
$1,012.49 / each
Qty

Product Details

Class 9
Ball on Motor, Heavy Duty Needle Roller and Thrust Balls on Case
Ball on Motor, Heavy Duty Needle Roller and Thrust Balls on Case
Adaptable to 5X400
None
United States
9.03 in
TEFC
60 Hz
3.8
3.8 A
Die Cast Aluminum
Hardened Steel
65:1
Helical (1st Stage), Spur (Subsequent Stages)
None
Totally Enclosed Fan-Cooled
All Angle
1
CW/CCW
Parallel
Single
AC Gearmotor
115V AC
1st Stage Helical, AGMA Class 9, Hardened Steel, Subsequent Stages Spur
Die Cast Aluminum
Die Cast Aluminum
60 Hz
0.167 hp
1/6 hp
Yes
64.6:1
1/16 in
Rounded
3/16 mm
9.88 in
Permanent Heavy Duty Gear Oil
40 Degrees C
275 in-lb
104 Degrees F
275 in-lb
Totally Enclosed Fan-Cooled
Split-Phase
1.5 in
4 in
Any Position
All Position
Any Angle
27 RPM
27 RPM
2
1
115V AC
5/8 in
3.5 in
1 1/2 in
5.13 in
6 in
175 lb
175 ft-lb
1
Single
CW/CCW
16 to 30
Lip Type on Input and Output Shaft
Lip Type on Input and Output Shaft
5/8 in
1.5
Parallel
C-UL Recognized, UL Recognized
None
115
