Home / AC Gearmotor, 500.0 in-lb Max. Torque, 6 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 500.0 in-lb Max. Torque, 6 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 500.0 in-lb Max. Torque, 6 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase
AC Gearmotor, 500.0 in-lb Max. Torque, 6 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase

AC Gearmotor, 500.0 in-lb Max. Torque, 6 RPM Nameplate RPM, 115/230V AC Voltage, 1 Phase

  • Dayton
  • AC Gearmotor, Number of Output Shafts 1, Motor Type Permanent Split Capacitor, Motor Enclosure Totally Enclosed Fan-Cooled, Nameplate Speed 6 RPM, Maximum Torque 500 in-lb, Overhung Load Capacity 300 ft-lb, Rotation CW/CCW, Mounting Orientation Any Angle, Operating Voltage 115/230V AC, Inverter Rated Yes, Gear Ratio 266:1, Brake Type None, Shaft Orientation Parallel, Motor Insulation Class B

    graingerSKU: 1LPX6, mscSKU: , zoro_no: G0373965, mongo_id: 65bbe65b3aaddbd5a9023a60

Web Price
$991.24 / each
Qty

Product Details

Ball and Needle on Case, Ball on Motor
Ball and Needle on Case, Ball on Motor
Adaptable to 5X400
None
Yes
United States
TEFC
Unpainted
50 Hz, 60 Hz
1.2/0.63
1.2/0.63 A
Die Cast Aluminum
Hardened Steel
266:1
Helical (1st Stage), Spur (Subsequent Stages)
None
Totally Enclosed Fan-Cooled
All Angle
1
CW/CCW
Parallel
Single
AC Gearmotor
115/230V AC
1st Stage Helical, Hardened Steel, Subsequent Stages Spur
Die Cast Aluminum
Die Cast Aluminum
Unpainted
60/50 Hz
0.083 hp
1/12 hp
b
Yes
266:1
1 in
0.18 Square x 1
0.18 sq in x 1 in
0.18 sq in x 1 in
3/16 in
9.5 in
Grease Filled
40 Degrees C
500 in-lb
104 Degrees F
500 in-lb
Totally Enclosed Fan-Cooled
B
Permanent Split Capacitor
3.63 in
Any Position
All Position
Any Angle
6 RPM
6 RPM
1
1
115/230V AC
3/4 in
1 3/8 in
4.88 in
5.63 in
300 lb
300 ft-lb
1
Single
No
CW/CCW
5
0 to 15
Lip Type on Input and Output Shaft
Lip Type on Input and Output Shaft
Single Output
3/4 in
1.38
Parallel
C-UL Recognized, UL Recognized
None
115/230
