Large Diaphragm Pressure Switch

SKU
Brand Dwyer Instruments
Categories
Description Large Diaphragm Pressure Switch

Web Price

$717.49 / each

Qty

Product Details

Agency Approvals CSA, FM, UL.

Country of Origin (subject to change) United States

Electrical Connections 3 screw type, common, normally open and normally closed.

Electrical Rating 15 A @ 120-480 VAC, 60 Hz. Resistive, 1/8 HP @ 125 VAC, 1/4 HP @ 250 VAC, 60 Hz.

Features Visible set point indicator simplifies operation and trouble shooting; Large diaphragm provides low range accuracy providing precise control; Current loads of up to 15 amps supports most small electrical loads supporting a broader range of HVAC and Process applications without the need for additional relays and components

Mounting Orientation Diaphragm in vertical position. Consult factory for other position orientations.

Package Quantity 1

Pressure Limits 10 psig (68.95 kPa) continuous, 25 psig (172.4 kPa) surge.

Process Connections 1/8 female NPT.

Repeatability ÃÂ±1%.

Service Air and non-combustible, compatible gases.

Set Point Adjustment Screw type with enclosed scale.

Switch Type SPDT.

Temperature Limits -30 to 110ÃÂ°F (-34.4 to 43.3ÃÂ°C).
