Home / Pressure Transmitter, 0 to 15 psi
Pressure Transmitter, 0 to 15 psi

Pressure Transmitter, 0 to 15 psi

  • Dwyer Instruments
  • Pressure Transmitter, Minimum Pressure 0 psia, Maximum Pressure 15 psia, Electrical Connections Cable & Wire Leads, Output 4 to 20mA DC, Accuracy +/-1 Percent of Full Scale, Number of Wires 2, Process Connection Gender Male, Process Connection Size 1/2 in, Process Connection Type NPT, Power Required 10 to 30V DC, NEMA Rating NEMA 4X, IP Rating IP66, Series 628, Wiring Entry Cable Gland, Maximum Operating Temperature 200 Degrees F, Minimum Operating Temperature 0 Degrees F

    graingerSKU: 3DRH3, mscSKU: , zoro_no: G0057084, mongo_id: 65bbe9f322d7a989a9988df0

Web Price
$269.99 / each
Qty

Product Details

+/-1% of Full Scale
+/-1.00%
3 ft
No
316L SS Wetted Parts
United States
CH Housing Only
Pressure
Cable & Wire Leads ; Cable Gland
3 ft. Pre-Wired Cable
3 ft Cable
IP66 ; NEMA 4X
No
Compact Design, Robust Sensor
Compressors, Hydraulics, Pumps
Compressors, Hydraulics, Pumps
Stainless Steel
Stainless Steel
Instructions
No
IP66
36
0 to 1300 ohms
1 yr
30 psi
0 to 1,000 Ohm Max
200 Degrees F
15 psia
0 Degrees F
0 psia
NEMA 4X
No
2
0 to 200 Degrees F
0 Degrees to 200 Degrees F
4 to 20 mA DC
4 to 20mA DC
3.5 in
5.5 in
1.281 in
45 psia
1
13 to 30 VDC
13 to 30V DC
0 psia to 15 psia
psia
1/2 in NPT
Male
1/2 in
1/2 in
NPT
MNPT
0 to 15 psi
psi
0 to 15
300 msec
CE
628
CE, NSF, UL Listed
+/-0.04%
Pressure Transmitter
Absolute
10 oz
316 SS and 316L SS
316 Stainless Steel, 316L Stainless Steel
Cable Gland
1/2 in FNPT
