Home / Circuit Breaker, 15 A, 600VAC, 1 Pole

Circuit Breaker, 15 A, 600VAC, 1 Pole

SKU
Brand Eaton
Categories
Description Circuit Breaker, 15 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 25 kA at 480V AC, For Use With Power Defense, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating Not Rated, Terminal Connection Standard Terminals Load Only, Trip Type Thermo Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection A, Frame Size 225A/Frame 2, Height 6 in, Width 1.38 in, Depth 3.5 in, Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG, Max. Operating Temp. 158 Degrees F
graingerSKU: 61HT67, mscSKU: , zoro_no: G000901885, mongo_id: 65bbe6a03aaddbd5a90407cd

Web Price

$362.49 / each

Qty

Product Details

AC Voltage Rating 600V AC

Amps 15 A

Certifications IEC 60947-2;CCC Marked;UL 489;CSA

Circuit Breaker Type Standard

Class Class A

Country of Origin (subject to change) Dominican Republic

Curve Type A

DC Voltage Rating Not Rated

Depth 3.5 in

For Use With Power Defense

Frame 2

Frame Size 225A/Frame 2

Frame Type Complete Breaker

Height 6 in

Instantaneous Trip Fixed

Interrupt Rating 25 kA at 480V AC, 20 kA lcu/lcs/42 kA Icm at 480V

Interrupt Rating Range 20 kAIC Icu/ 20 kAIC Ics/ 42 kAIC Icm @480V Brazil (IEC);10 kAIC Icu @125 Vdc;10 kAIC Icu @250 Vdc;25 kAIC Icu/ 25 kAIC Ics/ 52.5 kAIC Icm @380-415V (IEC);35 kAIC Icu/ 35 kAIC Ics/ 73.5 kAIC Icm @240V (IEC);14 kAIC @600V (UL/CSA);25 kAIC @480V (UL);25 kAIC Icu/ 20 kAIC Ics/ 52.5 kAIC Icm @440V (IEC);35 kAIC @240V (UL);18 kAIC Icu/ 15/13 kAIC Ics/ 37.8 kAIC Icm @525V South Africa (IEC)

Max. AIR Rating 25 kA at 480V AC

Max. Operating Temp. 158 Degrees F

Max. Wire Size 1/0 AWG

Min. Operating Temp. -4 Degrees F

Min. Wire Size 14 AWG

Number of Poles 1

Package Quantity 1

Phase Three

Phase Connection A

Product Height 152.4 mm

Product Length/Depth 88.9 mm

Product Name Eaton Power Defense molded case circuit breaker
