IEC Magnetic Contactor, 4 Poles, 24 V AC, 50 A, Reversing: No

SKU
Brand Eaton
Categories
Description IEC Magnetic Contactor, Auxiliary Contact Form Auxiliary Contacts Not Included, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 24V AC, Number of Poles 4, Full Load Current - Inductive 50 A, Full Load Current - Resistive 80 A, Reversing Capability Non-Reversing, Overall Height 5.9 in, Overall Width 4.6 in, Terminal Connection Type Screw Terminals, Frame Size D, Mounting Style DIN Rail, Panel, Series XT, Number of Auxillary Contacts 0, Contactor Style IEC
graingerSKU: 21EP13, mscSKU: , zoro_no: G6362885, mongo_id: 65bbe6ef3aaddbd5a906322e

Web Price

$424.99 / each

Product Details

Action Non-Reversing

Amperage Rating 80A

Aux. Contact Configuration No Auxiliary Contacts

Auxiliary Contact Form Auxiliary Contacts Not Included

Certifications CSA Certified;IEC 60947;UL Listed;EN 60947

Coil Voltage 24V AC

Coil Volts 24 V AC

Compliances CE Marked

Contact Configuration 0 NO, 0 NC

Contactor Style IEC

Country of Origin (subject to change) United States

Depth 5.2 in

Electrical Connection Screw Terminals

Embedded Surge Suppressor Yes

Enclosure NEMA Rating No Enclosure

Frame / Series / Class / Code Frame D

Frame Size D

Frequency 50/60 Hz

Frequency Rating 50-60 Hz

Full Load Amps-Inductive 50 A

Full Load Amps-Resistive 80 A

Full Load Current - Inductive 50 A

Full Load Current - Resistive 80 A

Height 3.35 in

Horsepower @ Single Phase - 240V AC 15 hp

Horsepower @ Three Phase - 208V AC 15 hp

Horsepower @ Three Phase - 240V AC 20 hp

Horsepower @ Three Phase - 480V AC 40 hp

Horsepower @ Three Phase - 600V AC 50 hp

HP @ 1 Phase - 230V 15

HP @ 1 Phase - 240V 15 hp

HP @ 3 Phase - 208V 15 hp

HP @ 3 Phase - 240V 20 hp

HP @ 3 Phase - 480V 40 hp

HP @ 3 Phase - 575V 50 hp

Hp Rating - Max 15, 20, 40, 50 hp (3PH @200,230,460,575 V)

Hz_ 50/60

Includes Auxiliary Contacts No

IP Rating IP20

Maximum Operating Temperature 122 Degrees F

Maximum Voltage Rating 690V AC

Mechanical Operating Durability 10,000,000

Minimum Operating Temperature -13 Degrees F

Mounting Hole Diameter 0.16 in

Mounting Hole Distance - Height 4.13 in

Mounting Hole Distance - Width 1.77 in

Mounting Style DIN Rail, Panel

NEMA Enclosure Material Not Applicable

NEMA Enclosure Rating No Enclosure

NEMA Size Not Applicable

Number of Auxillary Contacts 0

Number of Poles 4

Overall Depth 2.2 in

Overall Height 5.9 in

Overall Width 4.6 in

Package Quantity 1

Phase 3

Product Height 5.9 in

Product Length/Depth 2.2 in

Product Name Eaton XT IEC contactor

Product Width 4.6 in

Response Time 12 to 18 msec (AC Operated Closing Delay), 24 msec (DC Operated Opening Delay), 54 msec (DC Operated Closing Delay), 8 to 13 msec (AC Operated Opening Delay)

Reversing No

Reversing Capability Non-Reversing

Series XT

Standards CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed

Terminal Connection Type Screw Terminals

Type Full voltage non-reversing contactor

Width 3.35 in
