Home / Battery Terminal, Right Elbow, 4/0 ga, PK5

Battery Terminal, Right Elbow, 4/0 ga, PK5

SKU
Brand Eco-Max
Categories
Description Battery Terminal, Alignment Right Elbow, Connection Type Crimp, Gauge 4/0 ga, Color Code Yellow, Polarity Negative, Contact Material Copper, Tin, Overall Length 1 13/16 in, Overall Width 1.4 in, Overall Depth 0.6 in, Features Highest Conductivity Rating, Lead Free Copper, Tin Plated for Corrosion Resistance, Standards RoHS Compliant, SAE J-1811, Includes Bolt, Nut, Maximum Voltage 600V, Stud Size 3/8 in, Package Quantity 5
graingerSKU: null, mscSKU: null, zoro_no: G5635034, mongo_id: 65bbe5fe3aaddbd5a9ffdc33

Web Price

$67.11 / each

Qty

Product Details

Alignment Right Elbow

Color Yellow

Color Code Yellow

Connection Material Copper

Connection Type Crimp/Solder

Contact Material Copper

Country of Origin (subject to change) China

Depth 0.6301 in

Features Eco-Max Is The First Environmentally Friendly; The Post Top Design is Manufactured With The Highest Quality C11000 ETP (Electrolytic Tough Pitch) Copper and is Completely Lead Free; C11000 ETP Copper Battery Terminals Provide The Highest Conductivity Rating Compared to Any Competing Copper Design; Maximum Electrical Conductivity is 101% Iacs at 68 Degrees F, Typical Designs Fall At 20% And 32% Iacs at 68 Degrees F

Gauge 4/0 ga.

Includes Nut and Bolt

Length 1 81/97 in

Max. Voltage 600 V

Maximum Voltage 600V

Overall Depth 0.6 in

Overall Length 1 13/16 in

Overall Width 1.4 in

Package Quantity 5

Polarity Negative

Standards SAE: J-1811; RoHS

Type Left Elbow Terminals
