Cable, Cat 6, 23 AWG, 1000 ft, Gray

SKU
Brand Genspeed
Categories
Description Category Cable, Cable Length 1,000 ft, Conductor Gauge 23 AWG, Fire Rating Riser, Jacket Color Gray, Jacket Material PVC, Outside Diameter 1/4 in, Performance Category 6, Shielded Unshielded, Number of Conductors 8, Number of Pairs 4, NEC Article and Type 800 CMR, Standards ANSI/TIA/EIA 568-B.2-1, ANSI/TIA/EIA 862, ICEA S-102-700, ISO/IEC 11801 Ed. 2.0 (Class E), NEC/CEC Type CMP (NFPA 262), NEC/CEC Type CMR (UL 1666), UL 444, Package Type Pulling Pack, Solid/Stranded Solid, Bend Radius 1 in
graingerSKU: , mscSKU: , zoro_no: G2224722, mongo_id: 65bbe84622d7a989a98e7871

Web Price

$692.49 / each

Qty

Product Details

Bend Radius 1 in

Cable Length 1,000 ft

Category - Data Cable 6

Category Type 6

Conductor Gauge 23 AWG

Conductor Size - Data Cable 23 AWG

Country of Origin (subject to change) United States

Fire Rating Riser

Fire Rating - Data Cable Riser

Frequency 350 MHz

Installation Temp. Range 0 Degrees to 60 Degrees C

Item - Data Cable Category Cable

Jacket Color Gray

Jacket Material PVC

Jacket Material - Wire and Cable PVC

Length 1000 ft.

Maximum Frequency 350 MHz

Maximum Operating Temperature 140 Degrees F

Minimum Operating Temperature 14 Degrees F

NEC Article and Type 800 CMR

Number of Conductor Pairs 4

Number of Conductors 8

Number of Pairs 4

Operating Temp. Range -10 Degrees to 60 Degrees C

Outside Dia. 0.215 in

Outside Diameter 1/4 in

Package Quantity 1

Package Type Pulling Pack

Package Type - Data Cable Pulling Pack

Performance Category 6

Plenum Rated Yes

Pulling Force 32 lb

Shielded Unshielded

Shielded / Unshielded Unshielded

Solid / Stranded Solid

Solid/Stranded Solid

Spool Length 1,000 ft

Standards ANSI/TIA/EIA 568-B.2-1, ANSI/TIA/EIA 862, ICEA S-102-700, ISO/IEC 11801 Ed. 2.0 (Class E), NEC/CEC Type CMP (NFPA 262), NEC/CEC Type CMR (UL 1666), UL 444

Total Number of Conductors - Data Cable 8 (4 Pair)

Wire Size 23 AWG
