DC Power Supply, 24 to 28 V DC Output

SKU
Brand Ifm
Categories
Description DC Power Supply, Input Voltage 100 to 240 V AC, Output Voltage 24 to 28 V DC, Power Rating 300 W, Output Amps 12.5 A, Switching, Case Material Aluminum Alloy, Height 183 mm, Width 182 mm, Depth 59 mm, Hz 50 Hz/60 Hz, Phase - Electrical Single, IP Rating 65; 67, Hold Up Time 33/33 msec @ 100/230 V AC, Status Indicator Green LED

Web Price

$1,548.74 / each

Qty

Product Details

Ambient temperature [ÃÂ°C] -25...55

Case Material Aluminum Alloy

Communication interface IO-Link

Continuous shock resistance IEC 60068-2-27 30 g 6 ms / 20 g 11 ms

Country of Origin (subject to change) Czechia

Depth 59 mm

Dimensions [mm] 182 x 183 x 59

Efficiency (nominal voltage 120 V AC / 60 Hz) [%] 94.3

Efficiency (nominal voltage 230 V AC / 50 Hz) [%] 95.7

Electrical connection Connector: 1 x M12; coding: A; Locking: brass, Connector: 2 x M12; coding: A; Locking: brass, Connector: 1 x 7/8; Locking: brass

EMC EN 61000-4-2 CD 8 kV / failure criterion A EN 61000-4-2 AD 15 kV / failure criterion A EN 61000-4-3 80 Mhz...2.7 GHz / 20 V/m failure criterion A EN 61000-4-3 2.7 GHz...6 GHz kV / 10 V/m failure criterion A EN 61000-4-8 50 / 60 Hz / 30 A/m failure criterion A EN 61000-4-4 Burst 4 kV / failure criterion A EN 61000-4-5 Surge 2 kV Lx / Ly / failure criterion A EN 61000-4-5 Surge 4 kV L / PE / failure criterion A EN 61000-4-5 Surge 1 kV + / - / failure criterion A EN 61000-4-5 Surge 1 kV + - / PE / failure criterion A EN 61000-4-5 Surge 1 kV + - / PE / failure criterion A EN 61000-4-5 Surge 1 kV DC-OK / PE / failure criterion A EN 61000-4-6 0.15...80 MHz / 20 V failure criterion A EN 61000-4-11 0 V up to 1 cycle / failure criterion A EN 61000-4-11 40 % of V / 200 ms failure criterion A EN 61000-4-11 70 % of V / 500 ms failure criterion A EN 61000-4-11 0 V / 5000 ms failure criterion C VDE 0160 1550 V / 1.3 ms failure criterion A EN 55032 Class B EN 55032 Class B EN 55011 Class B EN 61000-3-2 EN 61000-3-3

Features Additional Diagnostics by Measuring Current, Voltage and Mains Quality as Well as Counting Operating Hours, Installation Without Control Cabinet, Protection of the Wiring Via Configurable Electronic Circuit Breakers

Height 183 mm

Hold Up Time 33/33 msec @ 100/230 V AC

Hz_ 50 Hz/60 Hz

Input current (nominal voltage 120 V AC / 60 Hz) [A] 3.2

Input current (nominal voltage 230 V AC / 50 Hz) [A] 1.68

Input Voltage 100 to 240 V AC

Input voltage DC [V] 110...300

Input voltage range AC [V] 100...240

IO-Link revision 1.1

IP Rating 65; 67

Mains buffering time (nominal voltage 120 V AC / 60 Hz) [ms] 44

Mains buffering time (nominal voltage 230 V AC / 50 Hz) [ms] 44

Materials housing: aluminium alloy; housing cap: PC; screws: steel bronzed

Max. height above sea level [m] 5000

Max. output current at max. output voltage [A] 10.7

Max. output current at min. output voltage [A] 12.5

Max. power-on delay time [ms] 1.3

Max. relative air humidity [%] 95; (relative humidity)

Min. process cycle time [ms] 2.2

Nominal frequency AC [Hz] 50...60

Nominal voltage AC [V] 230

Nominal voltage DC [V] 300

Number of output circuits 4

Operating Temp. Range -25 Degrees to 55 Degrees C

Output Amps 12.5 A

Output power (peak) [W] 600

Output power (permanent) [W] 300

Output Voltage 24 to 28 V DC

Output voltage DC [V] 24...28

Package Quantity 1

Phase - Electrical Single

Pollution degree 3

Power factor (nominal voltage 230 V AC / 50 Hz) 0.97

Power Rating 300 W

Protection IP 65; IP 67

Protection class I

SIO mode yes

Standards EN 55011, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2 AD, EN 61000-4-2 CD, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8

Status Indicator Green LED

Storage temperature [ÃÂ°C] -40...85

Style Switching

Transmission type COM3 (230,4 kBaud)

UnterstÃÂ¼tzte IO-Link Revision 1.1

Vibration resistance IEC 600068-2-6 2...17.8 HzÃÂ± 1.6mm / 17.8...500 Hz 2 g

Width 182 mm
