Pressure Sensor, Range -0.2 to 3.6 psi

Pressure Sensor, Range -0.2 to 3.6 psi

  • Ifm
  • Electronic Pressure Sensor, Range -0.2 to 3.6 psi, Analog Output 4 to 20mA or 0 to 10V DC, Control Output PNP, Programmable On/Off Setting, Power Required 18 to 30V DC, Process Connection 1/4 in NPT, Electrical Connection 4 Pin M12, Display 4 Digit LED, Wetted Materials Stainless Steel, Housing Material Stainless Steel, Operating Temp. Range -13 Degrees to 176 Degrees F, IP Rating 65/67, Max. Pressure 450 psi, Standards CE, CULus

    graingerSKU: 52PG29, mscSKU: , zoro_no: G5893015, mongo_id: 65bbee0c526e052139ae6a25

Web Price
$567.49 / each

Product Details

-25...80
4 to 20mA or 0 to 10V DC
4...20; (scalable 1:5)
37.5...250 mbar 15...100.4 inH2O 3.75...25 kPa 385...2550 mmWS
-12.5...200 mbar -5...80.2 inH2O -1.25...20 kPa -125...2040 mmWS
0...10; (scalable 1:5)
for industrial applications
<± 0,25 (BFSL) / <± 0,5 (LS); (Turn down 1:1; BFSL = Best Fit Straight Line; LS = limit value setting)
IO-Link
Connector: 1 x M12; coding: A; Contacts: gold-plated
PNP
Germany
< 35
0...4
0...4
0...50
4 Digit LED
4 Pin M12
PNP/NPN
DIN EN 61000-6-2 DIN EN 61000-6-3
Stainless Steel
<± 0,1; (Turn down 1:1)
0.5 mbar 0.2 inH2O 0.05 kPa 5 mmWS, 0.1 mbar 0.1 inH2O 0.01 kPa 1 mmWS
yes
application specific tag
function bit length pressure 16 device status 4 binary switching information 2, function bit length pressure 14 binary switching information 2
0.1
1.1
65/67
<± 0,05; (Turn down 1:1; per 6 months)
stainless steel (1.4404 / 316L); PBT+PC-GF30; PBT-GF20; PC
stainless steel (1.4404 / 316L); AI2O3 (96%; ceramics); FKM
10 bar 10000 mbar 4000 inH2O 1000 kPa
500
450 psi
3
2
ceramic-capacitive pressure measuring cell
-0.0125...0.25 bar -12.5...250 mbar -5...100.4 inH2O -1.25...25 kPa -127...2549 mmWS
liquids and gases
-25...80
30000 mbar 12000 inH2O 3000 kPa 306000 mmWS
1.1 mbar 0.5 inH2O 0.11 kPa 11 mmWS, 1.5 mbar 0.6 inH2O 0.15 kPa 15 mmWS
100; (500 V DC)
2000
100 million
2.3, 3
145
1
2
Number of digital outputs: 2; Number of analogue outputs: 1
Programmable
-13 Degrees to 176 Degrees F
18...30 DC; (to SELV/PELV)
normally open / normally closed; (parameterisable)
switching signal; analogue signal; IO-Link; (configurable)
yes
1
hysteresis / window; normally open / normally closed; switch-on/switch-off delay; Damping; Display unit; current/voltage output
250
18 to 30V DC
0.3
Sound engineering practice; can be used for group 2 fluids; group 1 fluids on request
10000 mbar 4000 inH2O 1000 kPa 102000 mmWS
1/4 in NPT
Smart Sensor ED2: Digital Measuring Sensor (0x000A), Identification and Diagnosis (0x4000), Smart Sensor: Process Data Variable; Device Identification, Device Diagnosis
IP 65; IP 67
III
-0.2 to 3.6 psi
<± 0,1; (with temperature fluctuations < 10 K; Turn down 1:1)
A; (when pin 2 not connected: B)
-12...249 mbar -4.8...100 inH2O -1.2...24.9 kPa -122...2539 mmWS, -12...249 mbar -4.8...100 inH2O -1.2...24.9 kPa -120...2540 mmWS
< 1.5
no (can be retrofitted)
yes
IEC 61131-9
-10.9...250 mbar -4.4...100.4 inH2O -1.09...25 kPa -112...2550 mmWS, -11...250 mbar -4.4...100.4 inH2O -1.1...25 kPa -110...2550 mmWS
DIN EN 60068-2-27 50 g (11 ms)
yes
yes
Gold-plated contacts
CE, CULus
-40...100
<± 0,4; (Turn down 1:1)
< 500
<± 0,2; (-0...80°C)
<± 0,2; (-0...80°C)
> 50; (depends on lubrication, seal and pressure rating)
2
COM2 (38,4 kBaud)
relative pressure
pulsed
UL Approval no. J012
-1000
DIN EN 60068-2-6 20 g (10...2000 Hz)
Stainless Steel
