Home / Single Gas Monitor, LCD Display, 2" W

Single Gas Monitor, LCD Display, 2" W

SKU
Brand Industrial Scientific
Categories
Description Single-Gas Detector, Replaceable Battery Yes, Product Type Single-Gas Detector, Display Screen Type LCD, Includes Probe No, Housing Color Black, Gas Detected Hydrogen Cyanide, Communication Protocol PC-Compatible Interface, Series GasBadge Pro, Battery Size 2CR, Operating Humidity - Maximum 99 Percent, Status Indicator LED, Rechargeable Battery No, Includes Mounting Hardware Yes, Battery Voltage 3 V, Resistance Properties Water Resistant, Operating Humidity - Minimum 0 Percent

Web Price

$1,394.99 / each

Qty

Product Details

Accuracy +/-10% (At Temperature of Calibration), +/-15% (Over Full Measurement Temperature)

Alarm Setting Adjustable

Alarm Setting Adjustment Adjustable Alarm Setting

Alarm Type Audible, Vibrating, Visual

Alarm Volume Level 95 dB

Alert Type Vibration

Battery Chemistry Lithium

Battery Life 2,600 hr

Battery Size 2CR

Battery Type CR2 Lithium

Battery Voltage 3 V

Chemical Formula CL2, CLO2, CO, CO/H2, H2, H2S, HCN, NH3, NO2, O2, PH3, SO2

Communication Protocol PC-Compatible Interface

Country of Origin (subject to change) United States

Data Logger Yes

Depth 1 7/64 in

Detects Hydrogen Cyanide

Display LCD

Display Screen Type LCD

Features Standard TWA and STEL

Gas Detected Hydrogen Cyanide

Gas Type HCN

Height 3 45/64 in

Housing Color Black

Housing Material Polycarbonate

Includes Attached Suspender Clip, Calibration Adapter and Tubing, Operating Instruction

Includes Mounting Hardware Yes

Includes Probe No

Interchangeable Sensors Yes

IP Rating IP64

Maintainability Maintainable

Manufacturer Warranty Length 1 yr

Measurement Range Hydrogen Cyanide (0 to 30 ppm in 0.1 ppm)

Number of Gases Detected 1

Operating Humidity - Maximum 99 %

Operating Humidity - Minimum 0 %

Operating Temp. Range -40 Degrees to 140 Degrees F

Operating Temperature - Maximum 140 Degrees F

Operating Temperature - Minimum -40 Degrees F

Overall Depth 1.1 in

Overall Height 3.7 in

Overall Width 2 in

Package Quantity 1

Power Source Battery

Product Type Single-Gas Detector

Rechargeable Battery No

Replaceable Battery Yes

Resistance Properties Water Resistant

Resolution 0.1 ppm

Sensor Life 1 yr (HCN)

Sensor Range 0 to 30 ppm

Sensor Type Infrared

Series GasBadge Pro

Standards ANZEx: Ex ia I/IIC T4, ATEX Ex ia I/Ex ia IIC T4, China Ex: Ex ia I/IIC T4, Cl II, Gr E-G, CMA: Ex ia I, CSA: Cl I, Gr A-D T4, Equipment Group and Category I M1/II 1G, Ex ia IIC T4, IECEX: Ex ia I/IIC T4, INMETRO: Ex ia IIC T4,UL: Cl I, Div 1, Gr A-D, T4, KC: Ex ia I/IIC T4

Status Indicator LED

Temperature Code T4

Width 2 in
