Pressure Transducer, 304L SS, 0 to 500 psi

SKU
Brand Johnson Controls
Categories
Description Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 500 psi, Electrical Connections 3-Pin Packard Connector, Output 0 to 10V DC, Accuracy +/-1.50 Percent, Number of Wires 2, Process Connection Gender Male, Process Connection Size 1/4 in, Process Connection Type SAE 45 Degrees Flare, Power Required 12 to 33V DC, IP Rating IP67, Series P599, Maximum Operating Temperature 212 Degrees F, Minimum Operating Temperature -40 Degrees F, Housing Material Stainless Steel
graingerSKU: , mscSKU: , zoro_no: G9536171, mongo_id: 65bbe9a522d7a989a996c2aa

Web Price

$134.99 / each

Product Details

Accuracy +/-1.5%

Accuracy - Transmitter +/-1.50%

Burst Pressure 259 bar

Calibration Certificate No

Calibration Certificate Included No

Compatible With All Media Compatible with 304L Stainless Steel, Including Ammonia

Country of Origin (subject to change) Mexico

Electrical Connection 3-Pin Packard Connector

Electrical Connections 3-Pin Packard Connector

Electrical Connections - Transmitter Packard Connector

Enclosure Rating IP67

Explosion/Fire Proof No

Features 10 Million Plus Full Scale Pressure Cycle Rated Life Span, Environmentally Protected Electronics, Industrial Duty Design

Fitting Material Stainless Steel

For Use With Any Corrosive or Non-Corrosive Pressure Medium That is Compatible with 304L Stainless Steel, Including Water, Condensate, Carbon Dioxide, Glycol, Most Refrigerants Including Ammonia, Many Other Compatible Fluids and Gases

For Use With Media Type Refrigerants

Housing 304L Stainless Steel

Housing Material Stainless Steel

Intrinsically Safe No

IP Rating IP67

Loop Resistance Minimum Between Transducer Body and Any Wire: 100 megaohm @ 500V DC

Manufacturers Warranty Length 3 yr

Max. Pressure (PSI) 500 psi

Maximum Loop Resistance 100 Mega Ohm @ 500V DC

Maximum Operating Temperature 212 Degrees F

Maximum Pressure 500 psi

Minimum Operating Temperature -40 Degrees F

Minimum Pressure 0 psi

NIST Traceable Certificate No

Number of Wires 2

Operating Temp. - Transmitter -40 Degrees to 212 Degrees F

Operating Temperature -40 Degrees F to 212 Degrees F

Output 0 to 10V DC

Output - Transmitter 0 to 10V DC

Overpressure 3x Range

Package Quantity 1

Power Required 12 to 33V DC

Power Required - Transmitters 12 to 33V DC

Pressure Range 0 psi to 500 psi

Pressure Range (In. WC) 0 to 2768

Pressure Units psi

Process Connection 1/4 in Male SAE 45 Degrees Flare

Process Connection Gender Male

Process Connection Size 1/4 in

Process Connection Size - Transmitter 1/4 in

Process Connection Type SAE 45 Degrees Flare

Process Connection Type - Transmitter SAE Flare Internal Thread

Range 0 to 500 psi

Range Units - Transmitter psi

Range Values - Transmitter 0 to 500

Response Time 5 msec

Safety Rating Class I Div. 2 Group A FCC Part 15 Class B; Class I Div. 2 Group B FCC Part 15 Class B; Class I Div. 2 Group C FCC Part 15 Class B; Class I Div. 2 Group D FCC Part 15 Class B

Series P599

Standards CE, RoHS, UL Listed

Storage Temperature Range -40 Degrees F to 257 Degrees F (-40 Degrees C to 125 Degrees C)

Transmitter Type Pressure Transmitter

Type of Pressure Sealed Gauge

Wetted Materials - Transmitters 304L Stainless Steel

Wiring Entry - Transmitter None
