Motor Starter Cover Switch Assy, 20A, 2P

SKU
Brand Killark
Categories
Description Motor Starter Cover and Switch Assembly, Switch Type 2-Pole, Amps 20 A, Voltage 600V AC, Type of Operator Switch Assembly, Material Cast Aluminum, For Use With Manual Motor Starting Switches, Height 4.625 in, Width 3 in, Depth 1.75 in
graingerSKU: , mscSKU: , zoro_no: G3503796, mongo_id: 65bbe6593aaddbd5a9023062

Web Price

$312.49 / each

Qty

Product Details

Accessory Type Motor Starter Cover and Switch Assembly

Amps 20 A

Application Provides manual starting and stopping of small AC or DC motors. Motor running protection when overload heaters are used. XSX Series (without overload protection) is ideally suited for across-the-line applications where a positive disconnect means is requi

Country of Origin (subject to change) United States

CSA File Number LR11714

Depth 1.75 in

Dimensions 5.563 in x 4 in x 5.563 in

For Use With Manual Motor Starting Switches

Frequency Rating 60 Hz

Hazardous Rating(s) Class I, Divisions 1 & 2, Groups C, D;Class I, Zones 1 & 2, Groups IIB, IIA;Class II, Divisions 1 & 2, Groups E, F, G;Class III, Divisions 1 & 2

Height 4.625 in

Horsepower - Maximum 3

Length 5.563 in

Material Cast aluminum

Package Quantity 1

Series XSX

Size 5.563 in x 4 in x 5.563 in

Special features Covers are cast copper-free aluminum alloy. Operating shaft is stainless steel. Ground flange joint between bolted cover and box provide required flame path. Provisions for padlocking switch in either ON or OFF position is standard.

Switch Type 2-Pole

Type Aluminum Manual Motor Starting Switch Without Overload Protection Cover Assembly

Type of Operator Switch Assembly

Voltage 600V AC

Voltage Rating 600 V

Width 3 in
