Diamond Turning Insert, Trigon, 3/8", 1/64"

SKU
Brand Kyocera
Categories
Description Diamond Turning Insert, Chip-Breaker Code GS, Inscribed Circle 3/8 in, TiCN+Al2O3+TiN, ANSI Code WNMG331GS, Chip-Breaker Style Medium Roughing, Clearance Angle 0 Degrees , Coating Process CVD
graingerSKU: null, mscSKU: null, zoro_no: G7433424, mongo_id: 65bbe64d3aaddbd5a901f95d

Web Price

$9.99 / each

Qty

Minimum order: 10

Product Details

ANSI Code WNMG331GS

Chip-Breaker Yes

Chip-Breaker Code GS

Chip-Breaker Style Medium Roughing

Clearance Angle 0 Degrees

Coating Process CVD

Corner Radius 1

Country of Origin (subject to change) Japan

Cutting Application Boring, External Turning, Facing, General to Interrupted Cutting, Internal Facing

Cutting Direction Neutral

Features Thickened Alumina with Good Thermal Resistance (Twice as Thick as Conventional Coating) and Specialized Post-Coating Process Prevents Adhesion

Finish - Machining TiCN+Al2O3+TiN

General Shape Trigon

Hole Type Straight Hole

Included Angle 80 Degrees

Inscribed Circle 3

Insert Code 331

Insert Holding Type Screw

Insert Shape Trigon

ISO Number WNMG060404GS

Manufacturer Grade CA025P

Material - Machining Carbide

Material Grade - Machining Micro Columnar Coating Structure
