Receptacle, 15 A Amps, 125V AC, Flush Mount, Standard Duplex Outlet, 5-15R, Ivory

SKU
Brand Legrand
Categories
Description Receptacle, Connection Orientation Straight, Current Rating 15 A, Grounding Isolated Ground, Housing Color Ivory, Housing Material Thermoplastic, Mount Type Flush, NEMA Receptacle Configuration 5-15R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Receptacle Type Duplex, Resistance Properties Impact Resistant, Standards ANSI/EEE C62.41 (Formerly IEEE 587) ANSI/IEEE C62.45, CSA Certified C22.2 No. 42, cUL, UL1449 UL 498, Voltage Rating 125V AC, Wiring Method Back, Side

Web Price

$32.86 / each

Qty

Product Details

Additional Electrical Protection Isolated Ground, Surge Protection

Additional Electrical Protections Isolated Grounding & Surge Protection

Amperage 15 A

Amps - Plugs and Receptacles 15

Amps - Plugs and Receptacles 15 A

Application Environment Commercial

Application Sector Commercial

Color Ivory

Color - Plugs and Receptacles Ivory

Connection Back and side wire

Connection Orientation Straight

Contact Material Copper Alloy

Corrosion Resistant Yes

Country of Origin (subject to change) Mexico

Current Rating 15 A

Environmental Conditions Flammability: UL94 V2

Face Plate Height 2.8 in

Face Plate Width 1.75 in

Grade Federal Specification

Grounding Isolated Ground

Horsepower Rating 1/2 hp

Housing Color Ivory

Housing Material Thermoplastic

HP_ 1/2 hp

Includes Grounding Clip, Mounting Hardware

Includes Mounting Hardware Yes

Isolated Grounding Yes

Item - Plugs and Receptacles Receptacle

Key Resistance Properties Standard Resistance

Market Commercial, Residential

Material Thermoplastic Polyester

Maximum Operating Temperature 131 Degrees F

Maximum Wire Size 10 AWG

Minimum Operating Temperature -4 Degrees F

Minimum Wire Size 14 AWG

Mount Hole Center-to-Center Height 3.82 in

Mount Hole Center-to-Center Width 0.94 in

Mount Type Flush

Mounting Type - Plugs and Receptacles Flush

NEMA Configuration 5-15

NEMA Receptacle Configuration 5-15R

NEMA Receptacle Configuration - Plugs and Receptacles 5-15R

Number of Gangs 1

Number of Poles 2

Number of Poles & Wires 2 Pole / 3 Wire

Number of Wires 3

Outlet Type - Plugs and Receptacles Standard Duplex

Overall Depth 1.225 in

Package Quantity 1

Phase Single

Power Indicator Yes

Primary Resistance Properties Impact Resistant - 15 A

Receptacle Type Duplex

Resistance Properties Impact Resistant

Special Features Corrosion resistant

Standard cUL UL1449, UL498: CSA C22.2 No. 42: ANSI/EEE C62.41 (Formerly IEEE 587), ANSI/IEEE C62.45 Installation Categories Ã¢ÂÂ¬ÃÂAÃ¢ÂÂ¬ (Ring Wave) (Unidirectional Impulse).

Standards ANSI/EEE C62.41 (Formerly IEEE 587) ANSI/IEEE C62.45, CSA Certified C22.2 No. 42, cUL, UL1449 UL 498

Sub-Category Duplex Receptacles

Surge Protection Yes

Surge Suppression Yes

Tamper Resistant No

UL 94 Flammability Rating V-2

Visual Indicator Lights Power Connected

Voltage 125.0 V

Voltage - Plugs and Receptacles 125V AC

Voltage Rating 125V AC

Weather Resistant - Plugs and Receptacles No

Wiring Method Back, Side
