Home / Foot Switch, Air Air Foot Swit

Foot Switch, Air Air Foot Swit

SKU
Brand Linemaster
Categories
Description Heavy Duty Foot Switch, NEMA Rating 1, 13, 2, 4, Material Cast Iron, Color Orange, Momentary Action, Cord Type No Cord, Length 9 in, Width 5 7/8 in, Depth 4 3/8 in, IP Rating 56, Features Foot Guard, Shielded, Standards UL, Manufacturers Warranty Length 1 yr
graingerSKU: 35V848, mscSKU: 54097019, zoro_no: G3152515, mongo_id: 65bbe7e49a749db822760fe6

Web Price

$244.99 / each

Qty

Product Details

Action Momentary

Actions Momentary

Color Orange

Cord Type No Cord

Country of Origin (subject to change) United States

Depth 4 3/8 in

Features Foot Guard, Shielded

FEATURES & BENEFITS Designed for long life operation Nonskid Base Pad Plunger can be depressed flush with valve body without damage to valve Standard 1/8-27 N.P.T. input and output ports Filtered and lubricated air supply is required for best operation Line pressure up to 150 P.S.I. 2 holes provided for rigid mounting to floor or equipment Two-way models do not exhaust back pressure

Housing Colors Black

Housing Materials Cast Iron

Input & Output Ports 1/8-27 NPT Ports - Exposed

IP Rating 56

Length 9 in

Length (Straight Wireway) 9 in

Manufacturers Warranty Length 1 yr

Material Cast Iron

MATERIALS Internal Valve is constructed of a Non-Ferrous body, Stainless steel plunger and Teflon coated buna-N O-rings Air flows when plunger is depressed, stops flowing when plunger is released and exhausts back pressure on output side Air exhausts around plunger Operating temperature 0 to 131 ÃÂ°F (-18 to +55 ÃÂ°C) Rugged Cast Iron Housing

NEMA Rating 1, 13, 2, 4

Package Quantity 1

Pneumatic Valves 4-way air valve

PURPOSE Medium Duty General Purpose Design

Standards UL

Switch Type Pneumatic Airval

Width 5 7/8 in
