Pressure Gauge, 0 to 100 psi

SKU
Brand Midwest Instrument
Categories
Description Differential Pressure Gauge, Scale Type PSID, Pressure Range Minor Div. 2 lb., Rated Total Pressure 4000 PSI, Relay Type SPDT, Full Scale Accuracy ( Percent) 3/2/3 Percent, Connection Size NPT (In.) 1/4 FNPT, Amps AC 0.25, Dial Size (In.) 4-1/2, Ambient Operating Range (F) -40 to 200 Degrees F, Includes Installation and Operation Manual, Manufacturers Warranty Length 5 Year
graingerSKU: 22A529, mscSKU: , zoro_no: G5706391, mongo_id: 65bbe7163aaddbd5a9074095

Web Price

$1,127.49 / each

Qty

Product Details

Accuracy +/-3-2-3%

Accuracy Grade ASME B40.1 Grade B

Adjustable Set Points Yes

Ambient Operating Temperature Range -40 Degrees to 185 Degrees F (-40 Degrees to 85 Degrees C)

Application HVAC/R

Application - Max Pressure For High Operating Pressure

Basic Gauge Case Material Metal

Basic Gauge Wetted Parts Stainless Steel / Buna-N

Bezel Gasket Material Buna-N

Blowout Safety Back No

Body Material 316 Stainless Steel

Brand and Series MIDWEST INSTRUMENT 220

Case Diameter 6 3/16 in

Case Shape Round

Connection Location In-Line

Contact Rating 0.25A, 125V AC/V DC

Country of Origin (subject to change) United States

Dial Color White

Dial Material Engineered Plastic

Differential Gauge Connection Size 1/4 in

Differential Gauge Connection Type FNPT

Differential Pressure Gauge Type Differential Pressure Gauge

Differential Pressure Range 0 to 100 psi

Differential Pressure Range Units psi

Differential Pressure Range Value 0 to 100

Gauge Accuracy +/-3-2-3%

Gauge Case Material Plastic

Gauge Connection Location Inline

Gauge Nominal Dial Size 4 1/2 in

Gauge Operating Temp. Range -40 Degrees to 185 Degrees F

Gauge Primary Range Smallest Graduation 2

Hazardous Location Rating Class 1, Division 2, Groups A, B, C, D; Class 2, Division 2, Groups F, G

Housing Material 316 Stainless Steel

Includes Installation and Operation Manual

Includes Calibration Certificate No

Includes Mounting Hardware No

Includes Vent Plug No

IP/NEMA Rating NEMA 4X

Lens Material Acrylic

Manufacturer Warranty Length 5 yr

Manufacturers Warranty Length 5 yr

Max Pressure Application For High Operating Pressure

Maximum Working Static Pressure 4,000 psig

Movement Material 316 Stainless Steel; Ceramic Magnet

Nominal Dial Size 4 1/2 in

Non-Sparking No

Number of Switches 1

O-Ring Material Buna-N

Package Quantity 1

Panel-Mountable No

Piston Material Stainless Steel

Pressure Gauge Type Differential Pressure Gauge with Switch

Pressure Range 0 to 100 psid

Process Connection 1/4 in NPT Female

Process Connection Gender Female

Process Connection Location End

Process Connection Size 1/4 in

Process Connection Type NPT

Rated Total Pressure 4000 psi

Relay Type SPDT

Removable Bezel No

Repeatability +/-1%

Scale Type Pressure

Seal Material Buna-n

Sensor Material Buna-N

Sensor Type Piston

Series Series 220

Standards CSA & UL Certified to US and Canadian Standards, CSA & UL Certified: Class I, Division 1 / Groups B, C & D, Class II, Division 1 / Groups E, F & G, Class I, Division 2 / Groups A, B, C & D, Class II, Division 2 / Groups F & G, Certified for ATEX / IECEx, Ex d IIB + H2 Ex tb IIIC, IP65 (3000 PSIG SWP), Division 2 Units are NEMA 4X

Switch Contact Type SPDT

Switch Electrical Requirements 0.25A @ 125V AC/DC; 3W
