Pressure Gauge, 0 to 30 psi

SKU
Brand Midwest Instrument
Categories
Description Differential Pressure Gauge, Scale Type PSID, Pressure Range Minor Div. 1 lb., Rated Total Pressure 1500 PSI, Relay Type SPDT, Full Scale Accuracy ( Percent) 3/2/3 Percent, Connection Size NPT (In.) 1/4 FNPT, Amps AC 0.25, Dial Size (In.) 4-1/2, Ambient Operating Range (F) -40 to 200 Degrees F, Includes Installation and Operation Manual, Manufacturers Warranty Length 5 Year
graingerSKU: 22A544, mscSKU: , zoro_no: G5775585, mongo_id: 65bbe5c03aaddbd5a9fe47d5

Web Price

$1,454.99 / each

Qty

Product Details

Accuracy +/-3-2-3%

Accuracy Grade ASME B40.1 Grade B

Adjustable Set Points Yes

Ambient Operating Temperature Range -40 Degrees to 185 Degrees F (-40 Degrees to 85 Degrees C)

Application Filtration Monitoring, Pumps, Separators, Strainers, Valves

Application - Max Pressure For Medium Operating Pressure

Basic Gauge Case Material Plastic

Basic Gauge Wetted Parts Stainless Steel / Buna-N

Bezel Gasket Material Buna-N

Blowout Safety Back No

Body Material 316 Stainless Steel

Brand and Series MIDWEST INSTRUMENT 240

Case Diameter 6 3/16 in

Case Shape Round

Connection Location In-Line

Contact Rating 0.25A, 125V AC/V DC

Country of Origin (subject to change) United States

Dial Color White

Dial Material Engineered Plastic

Diaphragm Material Buna-N

Differential Gauge Connection Size 1/4 in

Differential Gauge Connection Type FNPT

Differential Pressure Gauge Type Differential Pressure Gauge

Differential Pressure Range 0 to 30 psi

Differential Pressure Range Units psi

Differential Pressure Range Value 0 to 30

Gauge Accuracy +/-3-2-3%

Gauge Case Material Plastic

Gauge Connection Location Inline

Gauge Nominal Dial Size 4 1/2 in

Gauge Operating Temp. Range -40 Degrees to 185 Degrees F

Gauge Primary Range Smallest Graduation 1

Hazardous Location Rating Class 1, Division 2, Groups A, B, C, D; Class 2, Division 2, Groups F, G

Housing Material 316 Stainless Steel

Includes Installation and Operation Manual

Includes Calibration Certificate No

Includes Mounting Hardware No

Includes Vent Plug No

IP/NEMA Rating NEMA 4X

Lens Material Acrylic

Manufacturer Warranty Length 5 yr

Manufacturers Warranty Length 5 yr

Max Pressure Application For Medium Operating Pressure

Maximum Working Static Pressure 1,500 psig

Movement Material Ceramic

Nominal Dial Size 4 1/2 in

Non-Sparking No

Number of Switches 1

O-Ring Material Buna-N

Package Quantity 1

Panel-Mountable No

Piston Material Stainless Steel

Pressure Gauge Type Differential Pressure Gauge with Switch

Pressure Range 0 to 30 psid

Process Connection 1/4 in NPT Female

Process Connection Gender Female

Process Connection Location End

Process Connection Size 1/4 in

Process Connection Type NPT

Rated Total Pressure 1500 psi

Relay Type SPDT

Removable Bezel No

Repeatability +/-1%

Scale Type Pressure

Seal Material Buna-n

Sensor Material Buna-N

Sensor Type Diaphragm

Series Series 240

Standards ASME B1.20.1, ASME B40.100, CSA-C22.2 No. 14, 25 and 30, UL Std. No. 50, 508, 698, and 1203, NEMA Std. No. 250, SAE J514, EN60079-0, EN60079-1 & EN61241-0, EN61241-1, EN13463-1

Switch Contact Type SPDT

Switch Electrical Requirements 0.25A @ 125V AC/DC; 3W
