Home / Enclosed Power Relay, Surface (Top Flange) Mounted, DPST-NO, 24V DC, 6 Pins, 2 Poles
Enclosed Power Relay, Surface (Top Flange) Mounted, DPST-NO, 24V DC, 6 Pins, 2 Poles
Enclosed Power Relay, Surface (Top Flange) Mounted, DPST-NO, 24V DC, 6 Pins, 2 Poles

Enclosed Power Relay, Surface (Top Flange) Mounted, DPST-NO, 24V DC, 6 Pins, 2 Poles

  • Omron
  • Enclosed Power Relay, Base Shape Square, Coil Voltage 24V DC, Contact Form DPST-NO, Current Rating 30 A, Electrical Connection Quick-Connect, Flat Pin Width 0.25 in, Number of Pins 6, Sealing Semi-Sealed, Status Indicator No Indicator, Contact Rating (AC) 25 A @ 240V, Horsepower @ 120V AC 1 1/2 hp, Horsepower @ 240V AC 3 hp, Mounting Style Top Flange, Push-To-Test Method Test Button, Body Depth 1.32 in, Body Height 2.7 in, Body Width 1.4 in, Coil Resistance 303 ohm
Web Price
$17.74 / each
Qty

Product Details

25A @ 240V
Square
Flange, Top Mount
1.32 in
1.319 in
2.7 in
1.417 in
1.4 in
1.988 in
Yes
2.5VA, 1.9W
303 ohm
24V DC
DC
24V DC
25A @ 220VAC
25A @ 220VAC
DPST-NO
DPST-NO
Silver Tin Indium
25 A @ 240V
Indonesia
30 A
2,000V AC between Contacts of Different Poles (DPST-NO Type), 2,000V AC between Contacts of Same Pole, 4,000V AC min./5,000V AC Typical between Coil and Contacts
1.99H, 1.40W, 1.32D
Quick-Connect
1/4 in Tab Terminal
Tab
100,000
Enclosed
Flame-Resist, No Contact Chattering for Momentary Voltage Drops up to 50% of Rated Voltage
0.25 in
Air Conditioners, Copy Machines, Facsimile Machines, Food Processing Equipment, Heater Switching Controllers, Lighting Controller, Microwaves, Motors, Office Equipment, Packers, Power Controllers
50/60 Hz
1 1/2 hp
3 hp
1 1/2
3
50/60 Hz
50/60
24V DC
1,000 megaohm
Enclosed Power Relay
250V AC
1,000,000
100 mA
Yes
Flange, Top
Bottom Flange
0.18 in
Top Flange
6
6
2
25 A
1.85 in
1.85 in
1
6
1.9 W
1.9 W
Manual Push Test Button
Test Button
Surface (Top Flange)
Flame-Resistant
30 msec
Semi-Sealed
G7L Series
Surface (Top Flange) / Square / 6 / 0.25 in
CSA Certified, TUV Certified, UL Listed, VDE/IEC950
AC and DC Indicator
