Home / General Purpose Relay, 12V DC Coil Volts, Square, 14 Pin, 4PDT

General Purpose Relay, 12V DC Coil Volts, Square, 14 Pin, 4PDT

SKU
Brand Omron
Categories
Description General Purpose Relay, Base Shape Square, Coil Voltage 12V DC, Contact Form 4PDT, Current Rating 5 A, Electrical Connection Plug-In, Flat Pin Width 0.102 in, Number of Pins 14, Pin Shape Round, Sealing Enclosed, Status Indicator LED Indicator, Contact Rating (AC) 0.8 A @ 250V, 3 A @ 250V, Contact Rating (DC) 1.5 A @ 30V, 3 A @ 30V, Horsepower @ 120V AC 1/6 hp, Horsepower @ 240V AC 1/6 hp, Mounting Style Plug-In, Push-To-Test Method Lockable, Body Depth 1.42 in, Body Height 1.1 in
graingerSKU: 5ZJ14, mscSKU: , zoro_no: G1640107, mongo_id: 65bbe80722d7a989a98d1b59

Web Price

$13.74 / each

Qty

Minimum order: 2

Product Details

AC Contact Rating - Relay 5A @ 240V

Base Shape Square

Base Type Square

Base Type - Plug In Relay Square

Body Depth 1.42 in

Body Depth - Relay 1.1 in

Body Height 1.1 in

Body Height - Relay 1.42 in

Body Width 0.85 in

Body Width - Relay 0.85 in

Coil Resistance 160 ohm

Coil Voltage 12V DC

Coil Voltage Type DC

Coil Volts 12V DC

Compatible Manufacturer Part Number PY14, PY14-02, PY14-Y1, PYF14A-E, PYF14A-N, PYF14S, PYFZ-14-E

Compatible with Manufacturer Model Number PY14, PY14-02, PY14-Y1, PYF14A-E, PYF14A-N, PYF14S, PYFZ-14-E

Compatible with Manufacturer Model Number [NEW] PY14, PY14-02, PY14-Y1, PYF14A-E, PYF14A-N, PYF14S, PYFZ-14-E

Compatible with Manufacturer Part Number PY14, PY14-02, PY14-Y1, PYF14A-E, PYF14A-N, PYF14S, PYFZ-14-E

Contact Form 4PDT

Contact Form - Relay 4PDT

Contact Material Silver Alloy

Contact Rating 5A @ 250VAC/30VDC

Contact Rating (AC) 0.8 A @ 250V, 3 A @ 250V

Contact Rating (DC) 1.5 A @ 30V, 3 A @ 30V

Country of Origin (subject to change) Japan

Current Rating 5 A

DC Contact Rating - Relay 5A @ 28V

Dielectric Strength 1,000V AC Between Contacts of Same Polarity, 2,000V AC Between Coil and Contact, 2,000V AC Between Contacts of Different Polarity

Electrical Connection Plug-In

Electrical Connection Type Pin

Electrical Operating Durability 200,000

Environmental Protection Enclosed

Features Cadmium Free Contacts

Flat Pin Width 0.102 in

Green Environmental Attribute RoHS 2011/65/EU Compliant

Horsepower @ 120V AC 1/6 hp

Horsepower @ 240V AC 1/6 hp

HP @ 120V 1/6 hp

HP @ 240V 1/6 hp

Input Voltage 12V DC

Insulation Resistance 100 megaohm

Item - Relay General Purpose Relay

Maximum Operating Temperature 140 Degrees F

Maximum Switching Voltage 125V DC, 250V AC

Mechanical Operating Durability 100,000,000

Minimum Operating Temperature -67 Degrees F

Motor Rated Yes

Mounting - Relay Plug In

Mounting Style Plug-In

Number of Pins 14

Number of Pins - Relay 14

Operating Current 0.8 A at 250V AC (Inductive Load), 1.5 A at 30V DC (Inductive Load), 3 A at 250V AC (Resistive Load), 3 A at 30V DC (Resistive Load)

Overall Depth 1.67 in

Overall Height - Relay 1.67 in

Package Quantity 1

Pin Shape Round

Pins 14

Power Consumption 0.9 W

Power Consumption - Relay 0.9 W

Push To Test Lockable

Push-To-Test Button Lockable Push Test Button

Push-To-Test Method Lockable

Relay Mounting Style Socket

Resistance Properties Shock-Resistant, Vibration-Resistant
