General Purpose Relay, 12V DC Coil Volts, Square, 5 Pin, SPDT

SKU
Brand Omron
Categories
Description General Purpose Relay, Base Shape Square, Coil Voltage 12V DC, Contact Form SPDT, Current Rating 10 A, Electrical Connection Quick-Connect, Flat Pin Width 0.187 in, Number of Pins 5, Pin Shape Flat, Sealing Enclosed, Status Indicator Mechanical Flag, Contact Rating (AC) 10 A @ 250V, 7.5 A @ 250V, Contact Rating (DC) 10 A @ 30V, 5 A @ 30V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC 1/2 hp, Mounting Style Plug-In, Push-To-Test Method Manual, Body Depth 1.4 in, Body Height 1.14 in
graingerSKU: , mscSKU: , zoro_no: G0368024, mongo_id: 65bbe6103aaddbd5a9004e8a

Web Price

$11.24 / each

Qty

Product Details

AC Contact Rating - Relay 10A @ 240V

Base Shape Square

Base Type Square

Base Type - Plug In Relay Square

Body Depth 1.4 in

Body Depth - Relay 1.14 in

Body Height 1.14 in

Body Height - Relay 1.4 in

Body Width 0.51 in

Body Width - Relay 0.51 in

Coil Resistance 278 ohm

Coil Voltage 12V DC

Coil Voltage Type DC

Coil Volts 12V DC

Compatible Manufacturer Part Number P2R-057P, P2R-05A, P2R-05P, P2RF-05, P2RF-05-E, P2RF-05-PU, P2RF-05-S

Compatible with Manufacturer Model Number P2R-057P, P2R-05A, P2R-05P, P2RF-05, P2RF-05-E, P2RF-05-PU, P2RF-05-S

Compatible with Manufacturer Model Number [NEW] P2R-057P, P2R-05A, P2R-05P, P2RF-05, P2RF-05-E, P2RF-05-PU, P2RF-05-S

Compatible with Manufacturer Part Number P2R-057P, P2R-05A, P2R-05P, P2RF-05, P2RF-05-E, P2RF-05-PU, P2RF-05-S

Contact Form SPDT

Contact Form - Relay SPDT

Contact Material Cadmium Free

Contact Rating 10A @ 250VAC/30VDC

Contact Rating (AC) 10 A @ 250V, 7.5 A @ 250V

Contact Rating (DC) 10 A @ 30V, 5 A @ 30V

Country of Origin (subject to change) Malaysia

Current Rating 10 A

DC Contact Rating - Relay 10A @ 28V

Dielectric Strength 1,000V AC Between Contacts of Same Polarity, 5,000V AC Between Coil and Contacts

Electrical Connection Quick-Connect

Electrical Connection Type Tab

Electrical Operating Durability 100,000

Environmental Protection Enclosed

Flat Pin Width 0.187 in

Frequency 50/60 Hz

Green Environmental Attribute RoHS 2011/65/EU Compliant

Horsepower @ 120V AC 1/3 hp

Horsepower @ 240V AC 1/2 hp

HP @ 120V 1/3 hp

HP @ 240V 1/2 hp

Input Voltage 12V DC

Insulation Resistance 1,000 megaohm

Item - Relay General Purpose Relay

Maximum Operating Temperature 158 Degrees F

Maximum Switching Voltage 125V DC, 380V AC

Mechanical Operating Durability 20,000,000

Minimum Operating Temperature -40 Degrees F

Motor Rated Yes

Mounting - Relay Plug In

Mounting Style Plug-In

Number of Pins 5

Number of Pins - Relay 5

Operating Current 10 A at 250V AC (Resistive Load), 10 A at 30V DC (Resistive Load), 5 A at 30V DC (Inductive Load), 7.5 A at 250V AC (Inductive Load)

Overall Depth 1.59 in

Overall Height - Relay 1.6 in

Package Quantity 1

Pin Shape Flat

Pins 5

Power Consumption 0.53 W

Power Consumption - Relay 0.5 W

Push To Test Manual

Push-To-Test Button Manual Push Test Button

Push-To-Test Method Manual

Relay Mounting Style Socket

Resistance Properties Shock-Resistant, Vibration-Resistant
