General Purpose Relays

SKU
Brand Omron
Categories
Description General Purpose Relays, Base Shape Square, Coil Voltage 110/120V AC, Contact Form 4PDT, Current Rating 9.2 mA, 10.8 mA, Electrical Connection PCB Terminal, Flat Pin Width 2.6 mm, Number of Pins 14, Status Indicator LED Indicator, Contact Rating (AC) 0.80 A @ 240V, 3 A @ 240V, Contact Rating (DC) 1.50 A @ 24V, 3 A @ 24V, Horsepower @ 120V AC 1/10 hp, Horsepower @ 240V AC 1/6 hp, Mounting Style Soldering, Push-To-Test Method Lockable, Body Depth 1.41 in, Body Height 1.73 in, Body Width 0.88 in

Web Price

$25.19 / each

Qty

Product Details

Base Shape Square

Body Depth 1.41 in

Body Height 1.73 in

Body Width 0.88 in

Coil Resistance 4,430 ohm

Coil Voltage 110/120V AC

Contact Form 4PDT

Contact Material Silver + Gold Plating

Contact Rating (AC) 0.80 A @ 240V, 3 A @ 240V

Contact Rating (DC) 1.50 A @ 24V, 3 A @ 24V

Country of Origin (subject to change) China

Current Rating 9.2 mA, 10.8 mA

Dielectric Strength 1,000V AC at 50/60 Hz for 1 min Between Contacts of the Same Polarity, 2,000V AC at 50/60 Hz for 1 min Between Coil and Contacts, Between Contacts of Different Polarity

Electrical Connection PCB Terminal

Electrical Operating Durability 200,000

Features Full Range of Sockets Covering Mounting by Screw, Box Clamp and Screw-Less Clamp Method, Screw-Less Clamp Terminal Sockets Available, Transparent Housing

Flat Pin Width 2.6 mm

Frequency 50/60 Hz

Horsepower @ 120V AC 1/10 hp

Horsepower @ 240V AC 1/6 hp

Insulation Resistance 100 megaohm

Maximum Operating Temperature 70 Degrees C

Maximum Switching Voltage 125V DC, 250V AC

Mechanical Operating Durability 50,000,000, 100,000,000

Minimum Operating Temperature -55 Degrees C

Minimum Switching Current 3 A

Mounting Style Soldering

Number of Pins 14
