Relay, 4Pin, SPST, 10A, 12VDC

SKU
Brand Omron
Categories
Description Flange Mount Relay, Base Shape Square, Coil Voltage 12V DC, Contact Form SPST-NO, Current Rating 10 A, Electrical Connection Quick-Connect, Flat Pin Width 0.187 in, Number of Pins 4, Sealing Flux Protection, Status Indicator No Indicator, Contact Rating (AC) 10 A @ 250V, Contact Rating (DC) 10 A @ 30V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC 1/2 hp, Mounting Style Top Flange, Body Depth 1.16 in, Body Height 1.73 in, Body Width 0.52 in, Coil Resistance 275 ohm
graingerSKU: , mscSKU: , zoro_no: G0944955, mongo_id: 65bbe5a83aaddbd5a9fd99d1

Web Price

$9.36 / each

Qty

Product Details

AC Contact Rating - Relay 10A @ 240V

Base Shape Square

Base Type Square

Body Depth 1.16 in

Body Depth - Relay 0.46 in

Body Height 1.73 in

Body Height - Relay 1.16 in

Body Width 0.52 in

Body Width - Relay 1.2 in

Coil Resistance 275 ohm

Coil Voltage 12V DC

Coil Voltage Type DC

Coil Volts 12V DC

Contact Form SPST-NO

Contact Form - Relay SPST-NO

Contact Material Silver Alloy

Contact Rating 10A @ 250VAC/30VDC

Contact Rating (AC) 10 A @ 250V

Contact Rating (DC) 10 A @ 30V

Country of Origin (subject to change) Malaysia

Current Rating 10 A

DC Contact Rating - Relay 10A @ 28V

Dielectric Strength 1,000V AC Between Contacts of Same Polarity, 3,000V AC Between Contacts of Different Polarity, 5,000V AC Between Coil and Contacts

Electrical Connection Quick-Connect

Electrical Connection Type Tab

Electrical Operating Durability 100,000

Environmental Protection Flux Sealed

Features Creepage Distance of 8.0 mm M in Between Coil and Contact

Flat Pin Width 0.187 in

Frequency 50/60 Hz

Horsepower @ 120V AC 1/3 hp

Horsepower @ 240V AC 1/2 hp

HP @ 120V 1/3 hp

HP @ 240V 1/2 hp

Input Voltage 12V DC

Insulation Resistance 1,000 megaohm

Item - Relay Flange Mount Relay

Maximum Operating Temperature 158 Degrees F

Maximum Switching Voltage 125V DC, 380V AC

Mechanical Operating Durability 20,000,000

Minimum Operating Temperature -40 Degrees F

Minimum Switching Current 100 mA

Motor Rated Yes

Mounting Top

Mounting - Relay Top Flange

Mounting Hole Diameter 0.05 in

Mounting Style Top Flange

Number of Pins 4

Number of Pins - Relay 4

Operating Current 10 A at 250V AC (Resistive Load), 10 A at 30V DC (Resistive Load), 5 A at 30V DC (Inductive Load), 7.5 A at 250V AC (Inductive Load)

Overall Depth 1.5 in

Overall Height - Relay 1.49 in

Package Quantity 1

Pins 4

Power Consumption 0.5 W

Power Consumption - Relay 0.5 W

Relay Mounting Style Surface (Top Flange)

Resistance Properties Contact-Resistant, Insulation-Resistant, Shock-Resistant, Vibration-Resistant

Response Time 5 msec

Sealing Flux Protection

Series G2R Power Series

Socket Code Configurator Surface (Top Flange) / Square / 4 / 0.187 in
