Safety Relays

SKU
Brand Omron
Categories
Description Safety Relays, Base Shape Square, Coil Voltage 12V DC; 24V DC, Contact Form SPDT, Current Rating 21 mA, Electrical Connection Plug-In, Flat Pin Width 2.4 mm, Number of Pins 5, Status Indicator No Indicator, Contact Rating (AC) 1 A @ 240V, 2 A @ 240V, Contact Rating (DC) 2.00 A @ 24V, 5 A @ 24V, Body Depth 1.25 in, Body Height 1.31 in, Body Width 0.39 in, Coil Resistance 1,150 ohm, Compatible with Manufacturer Model Number P7TF-05, Contact Material Silver Tin Indium
graingerSKU: , mscSKU: , zoro_no: G510190458, mongo_id: 65bbe8d122d7a989a99195fe

Web Price

$34.69 / each

Qty

Product Details

Base Shape Square

Body Depth 1.25 in

Body Height 1.31 in

Body Width 0.39 in

Coil Resistance 1,150 ohm

Coil Voltage 12V DC; 24V DC

Compatible Manufacturer Part Number P7TF-05

Compatible with Manufacturer Model Number P7TF-05

Contact Form SPDT

Contact Material Silver Tin Indium

Contact Rating (AC) 1 A @ 240V, 2 A @ 240V

Contact Rating (DC) 2.00 A @ 24V, 5 A @ 24V

Country of Origin (subject to change) China

Current Rating 21 mA

Dielectric Strength 1,000V AC, 50/60 Hz for 1 minute Between Contacts of the Same Polarity, 2,000V AC, 50/60 Hz for 1 minute Between Coil and Contacts

Electrical Connection Plug-In

Electrical Operating Durability 1,000,000

Features All Output Relays Provide a Long Endurance (1,000,000 Operations at 5 A), While all Input Relays Provide Microswitching Power (100 uA at 1 V)

Flat Pin Width 2.4 mm

For Use With Sockets

Frequency 50/60 Hz

Insulation Resistance 100 megaohm

Maximum Operating Temperature 70 Degrees C

Maximum Switching Voltage 125V DC, 250V AC

Mechanical Operating Durability 50,000,000

Minimum Operating Temperature -40 Degrees C

Number of Pins 5

Overall Depth 1.53 in

Package Quantity 1

Power Consumption 0.5 W
