HTAP, Copper, Tin-Plated

SKU
Brand Panduit
Categories
Description H Tap, Color Code Brown, For Maximum Tap Wire Size Tap 1: 2 AWG, Tap 2: 8 AWG, Tap 3: 8 AWG, For Minimum Tap Wire Size Code Tap 1: 6 AWG, Code Tap 2: 14 AWG, Code Tap 3: 14 AWG, Flex Tap 1: 8 AWG, Flex Tap 2: 14 AWG, Flex Tap 3: 14 AWG, For Maximum Run Wire Size Code: 2 AWG, Flex: 2 AWG, For Minimum Run Wire Size Code: 6 AWG, Flex: 8 AWG, Material Copper, Maximum Voltage 600 V, Finish Tin Plated, Standards CSA Certified, UL Listed, Termination Style Crimp
graingerSKU: 21WJ53, mscSKU: , zoro_no: G2997377, mongo_id: 65bbe8979a749db82279eb53

Web Price

$27.36 / each

Qty

Product Details

Color Code Brown

Compatible Installation Tool Model Number CT-2930/L, CT-2930/LE, CT-930

Compatible with Product Type Continuous Conductors

Conductor Size 2 to 6 Stranded/Solid, 2 to 8 Flex Run and Tap 1; 8 to 14 Code and Flex Tap 2 and 3

Country of Origin (subject to change) United States

Description/Special Features For Code and Flex Conductors

Finish Tin Plated

For Maximum Run Wire Size Code: 2 AWG, Flex: 2 AWG

For Maximum Tap Wire Size Tap 1: 2 AWG, Tap 2: 8 AWG, Tap 3: 8 AWG

For Minimum Run Wire Size Code: 6 AWG, Flex: 8 AWG

For Minimum Tap Wire Size Code Tap 1: 6 AWG, Code Tap 2: 14 AWG, Code Tap 3: 14 AWG, Flex Tap 1: 8 AWG, Flex Tap 2: 14 AWG, Flex Tap 3: 14 AWG

For Run Wire Size 2 AWG, 4 AWG, 6 AWG, 8 AWG

Includes (3) 94V-0 Cable Ties

Material Copper

Material of Construction Tin-Plated Copper

Maximum Run Conductors 2

Maximum Tap Conductors 6

Maximum Voltage 600 V

Overall Height 1 9/16 in

Overall Length 3/4 in

Overall Width 5/8 in

Package Quantity 1

Run Wire Size Range Code: 6 AWG - Code: 2 AWG, Code: 6 AWG - Flex: 2 AWG, Flex: 8 AWG - Code: 2 AWG, Flex: 8 AWG - Flex: 2 AWG

Special Features Slotted Design Allows Quick and Easy Assembly of Conductor to Htap Using Three Panduit 94V-0 Cable Ties Included

Standards CSA Certified, UL Listed

Strip Length 13/16 in

Tap Wire Size Range Code Tap 1: 6 AWG - Tap 1: 2 AWG, Code Tap 1: 6 AWG - Tap 2: 8 AWG, Code Tap 1: 6 AWG - Tap 3: 8 AWG, Code Tap 2: 14 AWG - Tap 1: 2 AWG, Code Tap 2: 14 AWG - Tap 2: 8 AWG, Code Tap 2: 14 AWG - Tap 3: 8 AWG, Code Tap 3: 14 AWG - Tap 1: 2 AWG, Code Tap 3: 14 AWG - Tap 2: 8 AWG, Code Tap 3: 14 AWG - Tap 3: 8 AWG, Flex Tap 1: 8 AWG - Tap 1: 2 AWG, Flex Tap 1: 8 AWG - Tap 2: 8 AWG, Flex Tap 1: 8 AWG - Tap 3: 8 AWG, Flex Tap 2: 14 AWG - Tap 1: 2 AWG, Flex Tap 2: 14 AWG - Tap 2: 8 AWG, Flex Tap 2: 14 AWG - Tap 3: 8 AWG, Flex Tap 3: 14 AWG - Tap 1: 2 AWG, Flex Tap 3: 14 AWG - Tap 2: 8 AWG, Flex Tap 3: 14 AWG - Tap 3: 8 AWG

Termination Style Crimp

Type Grounding

Wire Range Run and Tap 1: 2 to 6 AEH Stranded and Solid, 2 to 8 AWG Flex, Taps and 3: 8 to 14 AWG Code and Flex
