Home / Counter, Red LED, 6 Digits, 2.25" D

Counter, Red LED, 6 Digits, 2.25" D

SKU
Brand Red Lion Controls
Categories
Description Counter, Number of Digits 6, Red LED Display, Character Height 4 in, Max. Counts per Second 1, Input Signal 12VDC (SNK Mode), 28VDC (SRC Mode), Output Rating 24 V DC @ 100 mA, 24 V DC @ 50 mA, Output (2) Relay, Mounting Bracket, Height 7.875 in, Depth 2.25 in, Width 26 in, Scaler Yes, Preset 1, Power Required 21.6 to 250 V DC, 50 to 250 V AC, Min. On/Off Pulse 10 msec, Prescaling Range 0 to 99,999, Reset Type Front Panel Key, Interface RS485, Connector Type Plug-In Terminal Block

Web Price

$1,842.49 / each

Qty

Product Details

Accuracy +/-0.01%

Application Rate/Count Indication

Character Height 4 in

Connection Terminal Block

Connector Type Plug-In Terminal Block

Count - max -99999 to 999999

Counter Type Electronic Programmable Counter/Rate Meter

Country of Origin (subject to change) United States

Depth 2.25 in

Digits (6) 101.1 mm H - Red LED

Dimension 26.00W x 7.87H x 22.00D (660.4 x 199.8 x 558.8 mm)

Display Red LED

Fits Large Display Does Not Panel Mount

Height 7.875 in

Input Signal 12VDC (SNK Mode), 28VDC (SRC Mode)

Interface RS485

IP Rating IP65

Manufacturers Warranty Length Limited

Max. Counts per Second 1

Min. On/Off Pulse 10 msec

Mounting Bracket

NEMA Rating 4X

Number of Digits 6

Operator Nonvolatile EEPROM

Output (2) Relay

Output Rating 24 V DC @ 100 mA, 24 V DC @ 50 mA

Package Quantity 1

Power Required 21.6 to 250 V DC, 50 to 250 V AC

Prescaling Range 0 to 99,999

Preset 1

Product Type Large Display Counter

Reset Auto or Manual

Reset Type Front Panel Key

Scaler Yes

Special Features Built-in Batch Counting Capability, Dual 5 A Form C Relay, Programmable Scaling and Decimal Points, Programmable User Input, Universally Powered

Speed 35 kHz

Standards CE Approved, Emission CISPR 11 Class A, EN 61010-1, EN 61010-2-030, EN 61326-1, RoHS Compliant, UL File E137808

Voltage 250V AC

Width 26 in
