Pilot Ignitor System

SKU
Brand Robertshaw
Categories
Description Heating Kit, Product Type Heating Kit, Maximum Operating Temperature 175 Degrees F, Minimum Operating Temperature -40 Degrees F, Lock Out Time 90 sec, Pre-Purge Time 6 min, Number of Retries 3, Main Valve Current Output 1 A, Flame Sensor Current Output 0.7 mA, Ignition Cycle Time 90 seconds, Automatic Reset Time 1 hr, Compatible with Series Universal, Compatible with Brand Honeywell, Johnson Controls, Johnstone Supply, Uni-Line, White-Rodgers
graingerSKU: 4E397, mscSKU: , zoro_no: G2517365, mongo_id: 65bbe8569a749db822787069

Web Price

$413.74 / each

Qty

Product Details

Amps AC 1.5 A

Automatic Reset Time 1 hr

BtuH Capacity 200,000 / 320,000

Compatible with Brand Honeywell, Johnson Controls, Johnstone Supply, Uni-Line, White-Rodgers

Compatible with Series Universal

Control Voltage 24V AC

Control Volts 24 V

Country of Origin (subject to change) Mexico

Flame Sensor Current Output 0.7 mA

For Fuel Type LP, Natural Gas

For Use With Residential, Commercial Heating Equipment

Gas Type LP/NG

Ignition Cycle Time 90 seconds

Includes 720-070 Valve, 780-845 Module, LP Regulator, Mounting Harness, Spark/Sensor Probe, Wiring Harness

Inlet/Outlet (In.) 1/2 x 3/4

Input Voltage 24V AC

Lock Out Time 90 sec

Main Valve Current Output 1 A

Maximum Capacity 150,000 BtuH

Maximum Operating Temperature 175 Degrees F

Method of Opening Slow Opening

Minimum Operating Temperature -40 Degrees F

Number of Retries 3

OEM Replacement Part Number 21D185, 4E397, 63013, 63014, 661616, 700-002, 700-007, 700-022, 700-027, 700022, 700027, 710-002, 710-007, 711002, 711007, 712-007, 712007, 9998-363, L36-987, L36987, L38-185, L38185, Q15GAA-1, Q15GAA1, VLV49A-602R, VLV49A-604R, VLV49A-605R, VLV49A-606R, VLV49A602R, VLV49A604R, VLV49A605R, VLV49A606R, Y8610H4010, Y86G1002, Y86G1036

Operation Description Convert Conventional Standing Pilot Systems To Intermittent Pilot Systems

Package Quantity 1

Pre-Purge Time 6 min

Pressure Setting Range (In. WC) 3.5 Nat./ 11 LP

Product Type Heating Kit

Series 712

Thermostat Anticipator Setting Thermostat Anticipator

Type Gas Ignition System Kit

Voltage 24
