Bimetallic Overload Relay 575Vac 14A Iec

SKU
Brand Schneider Electric
Categories
Description Bimetallic Overload Relay 575Vac 14A Iec
graingerSKU: null, mscSKU: null, zoro_no: G0854421, mongo_id: 65bbe5dd3aaddbd5a9ff06e8

Web Price

$89.36 / each

Qty

Product Details

Ambient Air Temperature For Operation -20-55ÃÂ°C without derating IEC 60947 || -30-60ÃÂ°C with derating IEC 60947

Ambient Air Temperature For Storage -40-70ÃÂ°C

Associated Fuse Rating 6 A gG signalling circuit VDE 0660 || 6 A gG signalling circuit IEC 60947

Auxiliary Contact Composition 1 NO + 1 NC

Connections - Terminals screw clamp terminals 1 1.5-4 mmÃÂ²solid || screw clamp terminals 2 1.5-4 mmÃÂ²solid || screw clamp terminals 1 0.75-4 mmÃÂ²flexible without cable end || screw clamp terminals 2 0.75-4 mmÃÂ²flexible without cable end || screw clamp terminals 1 0.34-2.5 mmÃÂ²flexible with cable end || screw clamp terminals 2 0.34-1.5 mmÃÂ²flexible with cable end

Control Type Red push-button trip test function || Blue push-button stop and manual reset || selector switch manual or automatic reset

Country of Origin (subject to change) Czechia

Depth 65 mm

Device Short Name LR2K

Fire Resistance 850ÃÂ°C IEC 60695-2-1

Flame Retardance V1 conforming to UL 94 || requirement 2 conforming to NF F 16-101 || requirement 2 conforming to NF F 16-102

Height 58 mm

Ip Degree Of Protection IP2X conforming to IEC 60529

Local Signalling trip indicator Yellow)

Mechanical Robustness shocks NO contact10 Gn for 11 ms IEC 60068-2-27 || shocks NC contact10 Gn for 11 ms IEC 60068-2-27 || vibrations NO contact2 Gn, 5 to 300 Hz IEC 60068-2-6 || vibrations NC contact2 Gn, 5 to 300 Hz IEC 60068-2-6

Mounting Support under contactor || plate, with specific accessories || rail, with specific accessories

Network Frequency <= 400 Hz

Network Type AC || DC

Operating Altitude 6561.68 ft (2000 m) without derating

Package Quantity 1

Phase Failure Sensitivity yes IEC 60947-4-1

Power Dissipation Per Pole 2 W

Product Certifications UL || CSA || UKCA

Product Compatibility LC7K || LP4K || LC1K || LP1K

Product Name TeSys LRK

Product Or Component Type differential thermal overload relay

Protective Treatment TC IEC 60068 || TC DIN 50016

Range TeSys

Rated Insulation Voltage Power circuit 690 V BS 4941; Power circuit 690 V IEC 60947; Power circuit 750 V VDE 0110 group C; Power circuit 600 V CSA C22.2 No 14

Rated Operational Voltage Less than or Equal to 690 V power circuit; 690 V AC AC-15 signalling circuit; 250 V DC DC-13 signalling circuit

Relay Application motor protection

Standards IEC 60947 || BS 4941 || VDE 0660 || NF C 63-650

Thermal Overload Class class 10A IEC 60947-4-1

Thermal Protection Adjustment Range 10-14 A

Tightening Torque 1.3 N.m screw clamp terminals Philips No 2 || 1.3 N.m screw clamp terminals flat ÃÂ 6 mm || 1.3 N.m screw clamp terminals pozidriv No 2

Width 45 mm

[Ith] Conventional Free Air Thermal Current 6 A signalling circuit

[Ue] Rated Operational Voltage <= 690 V power circuit || 690 V AC AC-15 signalling circuit || 250 V DC DC-13 signalling circuit

[Uimp] Rated Impulse Withstand Voltage 6 kV

[Ui] Rated Insulation Voltage power circuit 690 V BS 4941 || power circuit 690 V IEC 60947 || power circuit 750 V VDE 0110 group C || power circuit 600 V CSA C22.2 No 14
