Home / Hermetically Sealed Relay, 24V DC Coil Volts, Square, 14 Pin, 4PDT
Hermetically Sealed Relay, 24V DC Coil Volts, Square, 14 Pin, 4PDT

Hermetically Sealed Relay, 24V DC Coil Volts, Square, 14 Pin, 4PDT

  • Schneider Electric
  • Hermetically Sealed Relay, Base Shape Square, Coil Voltage 24V DC, Contact Form 4PDT, Current Rating 5 A, Electrical Connection Quick-Connect, Flat Pin Width 0.09 in, Number of Pins 14, Pin Shape Flat, Sealing Hermetically Sealed, Status Indicator No Indicator, Contact Rating (AC) 5 A @ 120/240V, Contact Rating (DC) 5 A @ 28V, Horsepower @ 120V AC Not Rated, Horsepower @ 240V AC Not Rated, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.07 in, Body Height 1.37 in

    graingerSKU: 2DW71, mscSKU: 69532711, zoro_no: G2745215, mongo_id: 65bbe7649a749db822734825

Web Price
$79.56 / each
Qty

Product Details

5A @ 120/240V
Square
Square
Square
1.07 in
1.16 in
1.37 in
1.28 in
0.83 in
0.91 in
24V DC
DC
24V DC
8501NR45, 8501NR45B
8501NR45, 8501NR45B
8501NR45, 8501NR45B
8501NR45, 8501NR45B
4PDT
4PDT
Silver Tin Oxide
5A @ 120/240VAC, 5A @ 30VDC
5 A @ 120/240V
5 A @ 28V
China
5 A
5A @ 28V
Quick-Connect
Tab
Hermetically Sealed
Class 1 Div. 2, Hermetically Sealed
0.09 in
RoHS 2011/65/EU Compliant
Not Rated
Not Rated
Not Rated
Not Rated
Hermetically Sealed Relay
131 Degrees F
240V AC, 30V DC
-40 Degrees F
Not Rated - Not Rated
Plug In
Socket
Class I, Division 2
14
14
-40-131°F
20 ms - pick-up || 20 ms - drop-out
1.53 in
1.53 in
1
Flat
14
0.9 W
0.9 W
No
No Test Button
No Button
Socket
20 msec
Hermetically Sealed
Square D 8501R Miniature Series
Mfr. No. 8501NR45
G
Socket / Square / 14 / 0.09 in
CE Certified, CSA Certified, UL Listed
None
30 V DC; 240 V AC
