IEC Auxiliary Contact

IEC Auxiliary Contact

  • Schneider Electric
  • Auxiliary Contact Block, Current AC 10 A, Number of Contacts 4, Mounting Front, Number of Normally Open Contacts 0, Maximum Voltage Rating 690V AC, Number of Normally Closed Contacts 4, Terminal Connection Type Screw Clamp Terminals, Compatible with Series TeSys, TeSys Deca, TeSys F, IP Rating IP20

    graingerSKU: 3DB65, mscSKU: , zoro_no: G0708321, mongo_id: 65bbee3c526e052139afbd70

Web Price
$73.74 / each
Qty

Product Details

23 to 140°F (-5 to 60°C)
-76 to 176°F (-60 to 80°C)
10 A
Dark Gray
TeSys, TeSys Deca, TeSys F
screw clamp terminals 1 0.00 to 0.01 in² (1 to 4 mm²)flexible with cable end; screw clamp terminals 1 0.00 to 0.01 in² (1 to 4 mm²)flexible without cable end; screw clamp terminals 2 0.00 to 0.00 in² (1 to 2.5 mm²)flexible with cable end; screw clamp terminals 2 0.00 to 0.01 in² (1 to 4 mm²)flexible without cable end; screw clamp terminals 1 0.00 to 0.01 in² (1 to 4 mm²)rigid without cable end; screw clamp terminals 2 0.00 to 0.01 in² (1 to 4 mm²)rigid without cable end
Instantaneous
10 A (at 140°F (60°C))
France
10 A
42 mm
Normal environment
Mercury Free, Toxic Heavy Metal Free
Schenider LC1F Contactors
48 mm
Greater than 10 MOhm
IP20 conforming to IEC 60529
IP20
140 A AC conforming to IEC 60947-5-1; 250 A DC conforming to IEC 60947-5-1
1
690V AC
30 Mcycles
5 mA
17 V
Front
1.5 ms on de-energisation no overlap between NC and NO contact; 1.5 ms on energisation no overlap between NC and NO contact
4
4
0
4
0
9842.52 ft (3000 m)
1
100 A 1 s; 120 A 500 ms; 140 A 100 ms
4 NC
CB; UL; CSA; CCC; EAC; UKCA
TeSys Deca
GG fuse 10 A
TH IEC 60068
TeSys D LC1D; TeSys D CAD; TeSys F LC1F; TeSys F CR1F; TeSys Deca CAD; TeSys Deca LC1D
690 V IEC 60947-5-1; 600 V UL; 600 V CSA
6 A at 120 V AC-15; 1.04 A at 690 V AC-15; 0.55 A at 125 V DC-13; 0.1 A at 600 V DC-13
690 V AC 25 to 400 Hz
EN/IEC 60947-5-1, UL 60947-5-1, CSA C22.2 No 60947-5-1, GB/T 14048.5, CB, CCC, EAC, UKCA
Screw Clamp Terminals
15.05 lbf.in (1.7 N.m) flat 6 mm; 15.05 lbf.in (1.7 N.m) Philips No 2; 15.05 lbf.in (1.7 N.m) pozidriv No 2
690V AC
44 mm
