IEC Control Relay, 2NO/2NC, 480VAC, 10A

IEC Control Relay, 2NO/2NC, 480VAC, 10A

  • Schneider Electric
  • IEC Control Relay, Current Rating 10 A, Contact Form 2NO/2NC, Contact Rating (DC) 2 A @ 125/250/600V, Coil Voltage 480V AC, Contact Rating (AC) 10 A @ 120/240/480/600V, Relay Style IEC, Electrical Connection Screw Clamp, Mounting Style DIN Rail and Surface, Power Consumption 4.5 VA, IP Rating IP2X, Compatible with Series TeSys K Control Relays, Maximum Operating Temperature 122 Degrees F, Frequency 50/60 Hz, Body Depth 2.24 in, Body Height 2.28 in, Body Width 1.77 in

    graingerSKU: 2VLH7, mscSKU: , zoro_no: G2108547, mongo_id: 65bbe83422d7a989a98e020a

Web Price
$63.99 / each
Qty

Product Details

10A @ 120/240/480/600V
-25-50°C
-50-80°C
10 A gG <= 690 V IEC 60947 || 10 A gG <= 690 V VDE 0660
2.24 in
2.24 in
2.28 in
2.28 in
1.77 in
1.77 in
30VA Inrush, 4.5VA Sealed
without integral suppression device
standard
480V AC
480V AC
TeSys K Control Relays
1 x 0.34-1.5 mm²flexible with cable end || 1 x 0.34-2.5 mm²flexible with cable end || 1 x 0.75-0.75 mm²flexible without cable end || 1 x 1.5-1.5 mm²solid || 2 x 4-4 mm²flexible without cable end || 2 x 4-4 mm²solid
10A
2NO/2NC
(2) SPST-NC, (2) SPST-NO
Silver Nickel
10 A @ 120/240/480/600V
2 A @ 125/250/600V
control circuit
AC
drop-out <= 0.2 Uc 50/60 Hz 50°C) || operational 0.8...1.15 Uc 50/60 Hz 50°C)
10 A (at 122°F (50°C))
France
10 A
2.00A @ 125/250/600V
57 mm
CA2K
Screw Clamp
class C2 conforming to NF F 16-101 || class C2 conforming to NF F 16-102 || V1 conforming to UL 94
50/60 Hz
1.3-1.3 W 50/60 Hz
58 mm
4.5-4.5 VA 20°C)
50 Hz, 60 Hz
50/60
2 ms
480V AC
30-30 VA 20°C)
> 10 MOhm
IP2X conforming to VDE 0106
IP2X
IEC Style Control Relay
10000 cyc/h 20°C
122 Degrees F
10000000 cycles
-13 Degrees F
5 mA
17 V
Din Rail/Panel
DIN Rail, Surface
DIN Rail and Surface
0.5 m
1.5 ms on de-energisation between NC and NO contacts || 1.5 ms on energisation between NC and NO contacts
10
10
6561.68 ft (2000 m) without derating
10...20 ms coil de-energisation and NO opening || 10...20 ms coil energisation and NO closing || 15...25 ms coil de-energisation and NC closing || 5...15 ms coil energisation and NC opening
2.28 in
2.28 in
1
2 NO + 2 NC
4.5 VA
4.5 VA
UL || CSA || UKCA
TeSys CAK
control relay
TC IEC 60068
TeSys
690 V BS 5424; 690 V IEC 60947; 750 V VDE 0110 group C; 600 V CSA C22.2 No 14
Less than or Equal to 690 V AC Less than or Equal to 400 Hz
IEC
10 to 20 msec (Coil De-Energisation and NO Opening), 10 to 20 msec (Coil Energisation and NO Closing), 15 to 25 msec (Coil De-Energisation and NC Closing), 5 to 15 msec (Coil Energisation and NC Opening)
10 gn control relay open || 15 gn control relay closed
CSA Certified, RoHS Compliant, UKCA, UL Listed
0.8-1.3 N.m screw clamp terminals 1.5-4 mm² Philips M6
AC-15
2 gn 5-300 Hz control relay open || 4 gn 5-300 Hz control relay closed
0.4 lb
45 mm
10 A 50°C
480 V AC 50/60 Hz
<= 690 V AC <= 400 Hz
690 V BS 5424 || 690 V IEC 60947 || 750 V VDE 0110 group C || 600 V CSA C22.2 No 14
