Home / IEC Magnetic Contactor, 3 Poles, 24 V AC, 65 A
IEC Magnetic Contactor, 3 Poles, 24 V AC, 65 A

IEC Magnetic Contactor, 3 Poles, 24 V AC, 65 A

  • Schneider Electric
  • IEC Magnetic Contactor

    graingerSKU: , mscSKU: , zoro_no: G0850319, mongo_id: 65bbe92f22d7a989a993e75e

Web Price
$687.49 / each
Qty

Product Details

Motor Control, Resistive Load
1NO/1NC
24 V AC
Operational AC: 0.8 to 1.1 Uc (at -40 to 60°C 50 Hz), 0.85 to 1.1 Uc (at -40 to 60°C 60 Hz), 1 to 1.1 Uc (at 60 to 70°C 50/60 Hz), Drop-Out AC: 0.3 to 0.6 Uc (at -40 to 70°C 50/60 Hz)
Czechia
118 mm
Screw Clamp Terminals
Mercury Free, PVC Free, Toxic Heavy Metal Free
UL 94 V1
65 A
80 A
125 A (Type 2 Power Circuit), 160 A (Type 1 Power Circuit), 10 A (Control Circuit)
122 mm
13 VA (at 60 Hz 20°C), 15 VA (at 50 Hz 20°C)
10 hp
20 hp
20 hp
40 hp
50 hp
1.5 Ohm
6 kV
Yes
140 to 160 VA
Greater Than 10 Mohms (Control Circuit)
IP2X
11 kW (at 400V AC 50 Hz AC-4), 30 kW (at 380 to 400V AC 50 Hz AC-3), 37 kW (at 500V AC 50 Hz AC-3), 37 kW (at 660 to 690V AC 50 Hz AC-3), 18.5 kW (at 220 to 230V AC 50 Hz AC-3), 30 kW (at 415V AC 50 Hz AC-3), 37 kW (at 1000V AC 50 Hz AC-3), 30 kW (at 440V AC 50 Hz AC-3e), 30 kW (at 380 to 400V AC 50 Hz AC-3e), 37 kW (at 500V AC 50 Hz AC-3e), 37 kW (at 660 to 690V AC 50 Hz AC-3e), 18.5 kW (at 220 to 230V AC 50 Hz AC-3e), 30 kW (at 415V AC 50 Hz AC-3e), 37 kW (at 1000V AC 50 Hz AC-3e), 37 kW (at 500V AC 50 Hz), 30 kW (at 380 to 400V AC 50 Hz)
850°C
6 Mcycles
Plate, Rail
2.185 kg
1.5 ms
3
3600 cycles per min
12 to 26 ms (Closing), 4 to 19 ms (Opening)
CAT III
1
1000 kA @ 440V
600/690V
140 A @ 440V (AC Control Circuit), 1000 A @ 440V (Power Circuit)
520 A (at 40°C for 10 s Power Circuit), 900 A (at 40°C for 1 s Power Circuit)
690V AC
LC1D
15 G for 11 ms (Contactor Closed), 10 G for 11 ms (Contactor Open)
UL 508, EN 60947-5-1, EN 60947-4-1, IEC 60947-5-1, CSA C22.2 No 14, UL, CCC, BV, GL, GOST, RINA, LROS, DNV, UKCA, TH IEC 60068-2-30
5 mA (Control Circuit)
17 V (Control Circuit)
80 A (at 60°C Power Circuit), 10 A (at 60°C Control Circuit)
1.7 Nm (Control Circuit), 5 Nm (Power Circuit)
4 G (Contactor Closed), 2 G (Contactor Open)
4 to 5W
70 mm
Up to 9842.52 ft
