Legend Ring, Round

SKU
Brand Schneider Electric
Categories
Description Legend Ring, Round, Legend ARRESTO EMERGENZA, Legend/Background Color Black/Yellow, Material Plastic, Height 60 mm, Width 9.3 mm, Diameter 60 mm
graingerSKU: 55WG04, mscSKU: , zoro_no: G3548423, mongo_id: 65bbe6393aaddbd5a90159c5

Web Price

$83.36 / each

Qty

Product Details

Accessory / Separate Part Destination emergency stop mushroom head push-button

Ambient Air Temperature For Operation -40-70ÃÂ°C

Ambient Air Temperature For Storage -40-70ÃÂ°C

Bulb Base integral LED

Cap/Operator Or Lens Colour 2 colours choice

Compatibility Code XB4 || XB5

Country of Origin (subject to change) France

Current Consumption 18 mA

Device Presentation intermediate ring

Diameter 60 mm

Electrical Insulation Class class II IEC 61140

Electromagnetic Emission class B IEC 55011

Height 60 mm

Ik Degree Of Protection IK05 EN 50102

Ip Degree Of Protection IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653 || Type 13 UL 50E || Type 12 UL 50E || Type 4 UL 50E || Type 4X UL 50E

Label Dimensions ÃÂ 60 mm

Legend ARRESTO EMERGENZA

Legend/Background Color Black/Yellow

Light Source protected LED

Light Source Colour white or red

Marking black ARRESTO EMERGENZA yellow

Material Plastic

Operator Additional Information with illuminated ring

Package Quantity 1

Product Certifications UL Listed || CSA

Product Or Component Type illuminated marked legend ring

Protective Treatment TH

Resistance To Electromagnetic Fields 10 V/m IEC 61000-4-3

Resistance To Electrostatic Discharge 4 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

Resistance To Fast Transients 2 kV IEC 61000-4-4

Resistance To High Pressure Washer 7000000 Pa 55ÃÂ°C 0.1 m

Shape Round

Shape Of Signaling Unit Head round

Shock Resistance 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27

Signalling Type steady

Standards CSA C22.2 No 14 || EN/IEC 60947-5-1 || EN/IEC 60947-5-4 || UL 508 || EN/IEC 60947-1 || JIS C8201-5-1 || JIS C8201-1

Supply Voltage Limits 19.2-30 V DC || 21.6-26.4 V AC

Surge Withstand 1 kV IEC 61000-4-5

Vibration Resistance 5 gn 10-500 Hz)IEC 60068-2-6 || 25 mm peak to peak 2-10 Hz)IEC 60068-2-6

Width 9.3 mm

[Ui] Rated Insulation Voltage 24 V 3)EN/IEC 60947-1

[Us] Rated Supply Voltage 24 V AC/DC 50/60 Hz
