Open Power Relay, Surface Mounted, SPDT, 24V DC, 5 Pins, 1 Poles
Open Power Relay, Surface Mounted, SPDT, 24V DC, 5 Pins, 1 Poles

Open Power Relay, Surface Mounted, SPDT, 24V DC, 5 Pins, 1 Poles

  • Schneider Electric
  • Open Power Relay, Base Shape Square, Coil Voltage 24V DC, Contact Form SPDT, Current Rating 40 A, Electrical Connection Screw Terminal, Number of Pins 5, Sealing Open, Status Indicator No Indicator, Contact Rating (AC) 15 A @ 120V, 40 A @ 300V, 5 A @ 480/600V, Contact Rating (DC) 40 A @ 28V, Horsepower @ 120V AC 2 hp, Horsepower @ 240V AC 2 hp, Mounting Style Surface, Body Depth 2.49 in, Body Height 2.49 in, Body Width 2.5 in, Coil Resistance 290 ohm, Compatible with Grainger Part Number 6CVA2

    graingerSKU: 6CUV0, mscSKU: , zoro_no: G0821387, mongo_id: 65bbe94522d7a989a9944714

Web Price
$57.69 / each
Qty

Product Details

40A @ 300V
-67 to 131°F (-55 to 55°C)
-67 to 212°F (-55 to 100°C)
Square
Panel
2.49 in
3.12 in
2.49 in
2.31 in
2.5 in
2.5 in
Yes
10.0VA, 4.0W
290 ohm
24V DC
DC
24V DC
50-1289-P
50-1289-P
50-1289-P
50-1289-P
40A @ 300VAC/28VDC
1 NC + 1 NO
SPDT
SPDT
Silver Alloy
15 A @ 120V, 40 A @ 300V, 5 A @ 480/600V
40 A @ 28V
Silver alloy contacts
China
Open cover
40 A
40A @ 28V
1,500V AC Between Open Contacts, 2,200V AC Between Coil and Contact, 2,200V AC Between Poles
2.18H, 2.50W, 2.43D
>= 0.1 Uc AC/DC
Screw Terminal
Screw
Screw
100000 cycles resistive DC load
100,000
Open
Riveted Construction
50/60 Hz
2 hp
2 hp
1 1/2
1 1/2
50/60 Hz
50/60
24V DC
Open Power Relay
131 Degrees F
600V DC
-67 Degrees F
1,000 mA
2 hp 120...600 V AC 50/60 Hz
Yes
Panel
Surface
Surface
5
5
1
15 A at 120V AC (Tungsten Filament), 40 A at 28V DC (Resistive Load), 40 A at 300V AC (Resistive Load), 5 A at 480V AC (Resistive Load), 5 A at 600V AC (Resistive Load)
2.06 in
2.18 in
1
5
4 W, 10 VA
10.0 W
10 VA AC
4 W DC
UL Listed; CSA; CE
Power relay
40 A at 300 V AC (on resistive load) conforming to UL; 40 A at 28 V DC (on resistive load) conforming to UL; 5 A at 480 V AC (on resistive load) conforming to UL; 5 A at 600 V AC (on resistive load) conforming to UL; 15 A at 120 V AC (tungsten filament) conforming to UL
6...600 V AC 50-60 Hz; 6...250 V DC
Surface
30 msec
Open
199 Power Series
Surface / Square / 5
CE Certified, CSA Certified, UL Listed
10.62 to 15.05 lbf.in (1.2 to 1.7 N.m)
0.85...1.1 Un AC/DC
0.6
AWG 14
