Overload Module, 8 to 32A, Class 10, 3P

SKU
Brand Schneider Electric
Categories
Description Overload Module, Maximum Rated Motor Current Adjustment 32 A, Minumum Rated Motor Current Adjustment 8 A, Coil Voltage 110-240V AC/DC, Compatible with Series TeSys Ultra, Terminal Connection Type Wire Leads, Trip Class 10, Phase Single, Maximum Voltage Rating 690V AC, Reset Type Manual, Standards ASEFA, ATEX Compliant, CCC, CE, CSA, CSA C22.2, EAC, EN 60947-6-2, Green Premium RoHS/REACH, IEC 60947-6-2, UL Listed, Compatible with Grainger Part Number 5AB64, 5AB68
graingerSKU: 5AB92, mscSKU: , zoro_no: G1826167, mongo_id: 65bbe74b9a749db82272e8ab

Web Price

$222.49 / each

Qty

Product Details

Ambient Air Temperature For Operation -25-70ÃÂ°C

Ambient Air Temperature For Storage -40-85ÃÂ°C

Coil Voltage 110-240V AC/DC

Compatibility Code LUCC

Compatible Manufacturer Part Number LU2B32FU, LU2B38FU, LUB32, LUB320, LUB38, LUB380

Compatible with Manufacturer Model Number LU2B32FU, LU2B38FU, LUB32, LUB320, LUB38, LUB380

Compatible with Series TeSys Ultra

Control Circuit Voltage Limits 88 to 264 V AC 110 to 240 V in operation || 88 to 242 V DC 110 to 220 V in operation || 55 V AC 110 to 240 V drop-out || 55 V DC 110 to 220 V drop-out

Country of Origin (subject to change) France

Current Range 8.00 to 32.0A

Depth 60 mm

Device Application motor control || motor protection

Device Short Name LUCC

Features Earth Fault Protection

Fire Resistance 960ÃÂ°C parts supporting live components IEC 60695-2-12 || 650ÃÂ°C IEC 60695-2-12

Fixing Mode plug-in front face)

For Use With LUxS32 Power Bases, Mfr. Series LUxB32

Function Available protection against overload and short-circuit || protection against phase failure and phase imbalance || manual reset || earth fault protection

Heat Dissipation 3-3 W control circuit with LUB32 || 3-3 W control circuit with LUB38

Height 66 mm

Immunity To Microbreaks 3 ms

Immunity To Radioelectric Fields 10 V IEC 61000-4-6

Immunity To Voltage Dips 70 % / 500 ms IEC 61000-4-11

Ip Degree Of Protection IP20 front panel and wired terminals IEC 60947-1 || IP20 other faces IEC 60947-1 || IP40 front panel outside connection zone IEC 60947-1

Load Type single-phase motor

Maximum Operating Temperature 158 Degrees F

Maximum Rated Motor Current Adjustment 32 A

Maximum Voltage Rating 690V AC

Minimum Operating Temperature -13 Degrees F

Minumum Rated Motor Current Adjustment 8 A

Motor Power Kw 7.5 kW 400 to 440 V AC 50/60 Hz 1 phase

Network Frequency 40 to 60 Hz

Non-Dissipating Shock Wave 1 kV serial mode IEC 60947-6-2 || 2 kV common mode IEC 60947-6-2

Number of Poles 3

Operating Altitude 6561.68 ft (2000 m)

Operating Time 35 ms opening with LUB32 control circuit || 35 ms opening with LUB38 control circuit || 50 ms closing with LUB32 control circuit || 50 ms closing with LUB38 control circuit

Package Quantity 1

Phase Single

Product Certifications CE || UL || CSA || CCC || EAC || ASEFA || ATEX || Marine

Product Compatibility power base LUB32 || power base LUB38 || power base LUB320 || power base LUB380 || reversing contactor breaker LU2B32FU || reversing contactor breaker LU2B38FU

Product Name TeSys Ultra

Product Or Component Type advanced control unit

Product Specific Application basic protection and advanced functions, communication

Protective Treatment TH IEC 60068

Range TeSys

Reset manual reset

Reset Type Manual

Reset Type - Relay Manual

Resistance To Electrostatic Discharge 8 kV 3 in open air IEC 61000-4-2 || 8 kV 4 on contact IEC 61000-4-2

Resistance To Fast Transients 2 kV 3 serial link IEC 61000-4-4 || 4 kV 4 all circuits except for serial link IEC 61000-4-4

Resistance To Radiated Fields 10 V/m 3 IEC 61000-4-3

Safe Separation Of Circuit 400 V SELV between the control and auxiliary circuits IEC 60947-1 || 400 V SELV between the control or auxiliary circuit and the main circuit IEC 60947-1

Sensing Method Electronic

Shock Resistance 10 gn power poles open IEC 60068-2-27 || 15 gn power poles closed IEC 60068-2-27

Standards ASEFA, ATEX Compliant, CCC, CE, CSA, CSA C22.2, EAC, EN 60947-6-2, Green Premium RoHS/REACH, IEC 60947-6-2, UL Listed

Terminal Connection Type Wire Leads

Thermal Overload Class class 10 40-60 Hz -25-55ÃÂ°C IEC 60947-6-2 || class 10 40-60 Hz -25-55ÃÂ°C UL 508

Thermal Protection Adjustment Range 8-32 A

Thermal Setting Range (A) 8.00 to 32.00

Trip Class 10

Trip Class - Overload 10

Tripping Threshold 14.2 x Ir +/- 20 %

Typical Current Consumption 280 mA 110 to 240 V AC I maximum while closing with LUB32 || 280 mA 110 to 240 V AC I maximum while closing with LUB38 || 280 mA 110 to 220 V DC I maximum while closing with LUB32 || 280 mA 110 to 220 V DC I maximum while closing with LUB38 || 25 mA 110 to 240 V AC I rms sealed with LUB32 || 25 mA 110 to 240 V AC I rms sealed with LUB38 || 25 mA 110 to 220 V DC I rms sealed with LUB32 || 25 mA 110 to 220 V DC I rms sealed with LUB38

Utilisation Category AC-44 || AC-43 || AC-41

Vibration Resistance 2 gn 5-300 Hz power poles open IEC 60068-2-6 || 4 gn 5-300 Hz power poles closed IEC 60068-2-6

Voltage 110-240V AC/110-220V DC

Width 45 mm

[Uc] Control Circuit Voltage 110 to 240 V AC || 110 to 220 V DC

[Ue] Rated Operational Voltage 690 V AC

[Uimp] Rated Impulse Withstand Voltage 6 kV IEC 60947-6-2

[Ui] Rated Insulation Voltage 690 V IEC 60947-6-2 || 600 V UL 60947-4-1 || 600 V CSA C22.2 No 60947-4-1
