Single Phase Relay, 250VAC/DC Coil Volts, 1 C/O

SKU
Brand Schneider Electric
Categories
Description Single Phase Relay, Status Indicator No Indicator
graingerSKU: , mscSKU: 69652147, zoro_no: G0572041, mongo_id: 65bbe5a83aaddbd5a9fd9a04

Web Price

$189.99 / each

Qty

Product Details

Ambient Air Temperature For Operation -4 to 122ÃÂ°F (-20 to 50ÃÂ°C)

Ambient Air Temperature For Storage -40 to 158ÃÂ°F (-40 to 70ÃÂ°C)

Body Width - Relay 17.5 mm

Coil Volts 250VAC/DC

Compatibility Code RM17

Connections - Terminals Screw terminals, 1 x 0.5 to 1 x 4 mmÃÂ² AWG 20 to AWG 11) solid without cable end; Screw terminals, 2 x 0.5 to 2 x 2.5 mmÃÂ² AWG 20 to AWG 14) solid without cable end; Screw terminals, 1 x 0.2 to 2 x 2.5 mmÃÂ² AWG 24 to AWG 12) flexible with cable end; Screw terminals, 2 x 0.2 to 2 x 1.5 mmÃÂ² AWG 24 to AWG 16) flexible with cable end

Contact Form - Relay 1 C/O

Control Circuit Frequency 50 to 60 Hz +/- 10%

Country of Origin (subject to change) Indonesia

Current Rating 5A

Delay At Power Up 1000 ms DC; 500 ms AC

Dielectric Test Voltage 2 kV AC 50 Hz, 1 min IEC 60255-5; 2 kV AC 50 Hz, 1 min IEC 60664-1

Electrical Durability 100000 cycles

Electromagnetic Compatibility Emission standard for industrial environments conforming to IEC 61000-6-4; Emission standard for residential, commercial and light-industrial environments conforming to IEC 61000-6-3; Immunity for industrial environments conforming to NF EN/IEC 61000-6-2

Features For Power On LED (Green); For Relay On LED (Yellow); Non Reversible Polarity On Dc Supply; Overvoltage Or Undervoltage Detection; Self-Powered

Housing Material Self-extinguishing plastic

Hysteresis 5 to 20% threshold setting

Immunity To Microbreaks 20 ms

Insulation Resistance Greater than 500 MOhm 500 V DC IEC 60255-5; Greater than 500 MOhm 500 V DC IEC 60664-1

IP Degree Of Protection IP20 IEC 60529 terminals; IP30 IEC 60529 casing)

Local Signalling for power ON LED (green); for relay ON LED (yellow)

Maximum Measuring Cycle 150 ms measurement cycle as true rms value

Maximum Power Consumption in W 1 W DC

Maximum Switching Current 5 A AC/DC

Measurement Accuracy +/- 10% of the full scale value

Measurement Error Less than 1% over the whole range with voltage variation; 0.2%/ÃÂ°C with temperature variation

Measurement Range 65 to 260 V voltage AC 50/60 Hz; 65 to 260 V voltage DC

Mechanical Durability 30000000 cycles

Minimum Switching Current 10 mA 5 V DC

Mounting - Relay 35 mm symmetrical DIN rail conforming to EN/IEC 60715

Mounting Support 35 mm symmetrical DIN rail conforming to IEC 60715

Nominal Output Current 5 A

Non-Dissipating Shock Wave 4 kV IEC 60255-5; 4 kV IEC 60664-1; 4 kV IEC 61000-4-5

Operating Position Any position without derating

Operating Rate Less than or Equal to 360 operations/hour full load

Operating Temp. Range -20-50ÃÂ°C

Overvoltage Category III IEC 60664-1

Package Quantity 1

Polarity Non reversible polarity on DC supply

Pollution Degree 3 IEC 60664-1

Power Consumption - Relay 1 W; 0-3 VA

Power Consumption in VA 0 to 3 VA AC

Product Certifications GL; UL; GOST; CSA; C-tick

Product Or Component Type Voltage control relay

Product Specific Application For single-phase and DC supply

Quality Labels CE

Rated Insulation Voltage 250 V IEC 60664-1; 400 V IEC 60664-1

Rated Supply Voltage 110 to 240 V AC/DC 50/60 Hz +/- 10%

Relative Humidity 95% 131ÃÂ°F (55ÃÂ°C) IEC 60068-2-30

Relay Monitored Parameters Overvoltage or undervoltage detection; Self-powered

Relay Name RM17UAS

Relay Type Voltage control relay

Repeat Accuracy +/- 0.5% input and measurement circuit; +/- 1% time delay

Reset Time 1500 ms time delay

Shock Resistance 5 gn IEC 60068-2-27

Standards EN/IEC 60255-6; GL; UL; GOST; CSA; C-tick; CE

Supply Voltage Limits 50 to 270 V AC/DC

Switching Power 1250 VA

Switching Voltage 250 V AC/DC

Tightening Torque 5.31 to 8.85 lbf.in (0.6 to 1 N.m) IEC 60947-1

Time Delay Adjustable 0.1 to 10 s, 0 + 10% on crossing the threshold

Utilisation Category AC-12 IEC 60947-5-1; AC-13 IEC 60947-5-1; AC-14 IEC 60947-5-1; AC-15 IEC 60947-5-1; DC-12 IEC 60947-5-1; DC-13 IEC 60947-5-1; DC-14 IEC 60947-5-1

Vibration Resistance 0.35 mm 5 to 57.6 Hz)IEC 60068-2-6; 1 gn 57.6 to 150 Hz)IEC 60255-21-1

Width 0.69 in (17.5 mm)
