Ssr3 Ch, 25A-48-600VAC, ZC, 4-32 VDC

Ssr3 Ch, 25A-48-600VAC, ZC, 4-32 VDC

  • Schneider Electric
  • Ssr3 Ch,25A@48-600VAC,ZC,4-32 VDC

    graingerSKU: , mscSKU: , zoro_no: G5956585, mongo_id: 65bbe91d22d7a989a993607d

Web Price
$188.74 / each
Qty

Product Details

1100 V
-20-80°C
-40-100°C
8 pF for input/output
screw terminals 0.2 to 1.3 mm², AWG 24 to AWG 16) input || screw terminals 1.3 to 5.3 mm², AWG 16 to AWG 10) output
0.5-0.5 (with maximum load)
Mexico
SSM3
4 kV AC for input/output || 4 kV AC for input or output to case
500 V/µs off-state at maximum voltage
22-28 mA
1000 MOhm
IP20
25 A
0.1-25 A
for input status LED (green)
EAC || CSA || UL || CE
1 hp 40°C 240 V AC || 2 hp 40°C 380 V AC || 3 hp 40°C 480 V AC
410 A².s for 10 ms at 50 Hz || 374 A².s for 8.3 ms at 60 Hz
0.25 mA off-state
<1.35 V on-state
symmetrical DIN rail
3
zero voltage switching
48 to 600 V AC
III
1
3 phase
2
CSA || UL || EAC
solid state relay up to 30 A
0.5 cycle (turn-on) || 0.5 cycle (turn-off)
zero voltage switching
CSA C22.2 No 14 || IEC 60950-1 || UL 508
286 A 20 ms 50 Hz || 300 A 16.6 ms 60 Hz
4 V DC turn-on || 1 V DC turn-off
0.6 to 0.7 N.m for input || 1.36 to 1.7 N.m for output
4 to 32 V DC
